1396095 Festo Vacuum Cups
Part#:1396095
Alt. Part#:VAS-55-1/4-PUR-B
Manufacturer:Festo
Category:Vacuum Cups
Product Lifecycle:Active
Product description
suction cup VAS-55-1/4-PUR-B Sealing ring is not included in the scope of delivery. Suction cup height compensator: 3,5 mm, Nominal size: 4 mm, suction cup diameter: 55 mm, suction cup volume: 8,01 cm3, Effective suction diameter: 44,7 mm
Product Details
- Nominal width 4 mm
- Effective suction cup diameter 44.7 mm
- Connection position Top
- Ambient temperature -20 °C ... 60 °C
- Type of mounting Via vacuum connection
- Note on materials RoHS-compliant
- Suction cup diameter 55 mm
- Operating medium Atmospheric air based on ISO 8573-1:2010 [7:-:-]
- Vacuum connection G1/4
- Suction cup material PUR
- Suction cup height compensation 3.5 mm
- Mounting position Any
- Holding force at nominal operating pressure 110 N
- Shore hardness 60 +/- 5
- Type code VAS
- Symbol 00991485
- Operating pressure -0.95 bar ... 0 bar
- Nominal operating pressure -0.7 bar
- Color Blue
- Suction cup volume 8.01 cm³
- Suction cup shape Round, flat
- Corrosion resistance class (CRC) 2 - Moderate corrosion stress
- Product weight 30 g
- Material of screwed trunnion Die-cast zinc
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
