TL30BGRXXXNXQD Banner Signal Towers

TL30BGRXXXNXQD on Powermatic Associates

Part#:TL30BGRXXXNXQD

Manufacturer:Banner

Alt. Part#:805380

Product Lifecycle:Active

Get a quick Quote!

TL30 Basic Tower Light; Black Housing: 2-Color Indicator; Voltage: 12-30 V dc; Environ. Rating: IP65; Input: Bimodal; Colors: Green Red; 5-pin M12 Integral QD

About the manufacturer: Banner is one of the manufacturers that offers Signal Towers that you can order at Powermatic Associates site. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.

Check out the TL30BGRXXXNXQD Banner price in the box on the right side or send a quick quote.

Product Details

Weight
104.779752 g
Country Of Origin
MX
Pro-Editor Compatible (Discrete)
No
Feature: Chemical Resistant
No
Primary Housing Color
Black
Max Op. Relative Humidity Non-Condensing (%)
90% @ 50°C
Wireless
No
IO Link
No
Modbus RTU
No
Multi-Color Device
Simultaneous Colors On
Feature: Audible
No
Feature: Hazardous Area
No
Feature: Quick Disconnect
Yes
Storage Temp (°C)
-40 to 70
Min Op. Temperature (°C)
-40
Max Op. Temperature (°C)
50
Primary Window Material
Polycarbonate Diffused
NEMA Type and UL Type Rating
UL 4X, 13
Environmental Rating
IP65
Physical Dimensions (LxWxH or DxH mm)
30.0 x 130.7

Max Input Response Time (ms)

1

Input Type

Bimodal (PNP/NPN)

Number of Input Pins/Conductors

5

Color 2 - Wavelength/Color Temp/Coordinates

625 nm

Supply Voltage

12-30 V dc

Max Current Color (mA)

40

Lumens Color 2

2.5

Color 1 - Wavelength/Color Temp/Coordinates

525 nm

Color Option 2

Red

Quick Disconnect Type

M12 (Euro)

Lumens Color 1

7.5

Number of Tower Light Segments

2

Connection

Integral QD

Animation Option 1

Solid On

Color Option 1

Green

Color Technology

Standard LED

Number of Colors / Segments

2

Product Size (mm)

30

Mounting Thread

M22 x 1.5

Primary Housing Material

Polycarbonate

Power Source

DC

Indication

Yes

Housing Style

Base Mount - Tower

Color Input Control

Individual (One wire/color, same number of colors as input wires)

Power

DC

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

TL30BGRXXXNXQD Description

Banner Engineering TL30BGRXXXNXQD is a tower light from the Basic series, designed with a 2-tiers 2-color G+R color pattern LED illumination. This monolithic tower light features a polycarbonate (PC) diffused window and a polycarbonate (PC) base, ensuring durability. It has a diameter of 30mm / 1-3/16" and is pre-equipped with a 5-pin M12 Euro-style QD connector for easy connection. The housing is black, and it operates on a supply voltage of 12Vdc-30Vdc (24Vdc nom.). It offers versatile mounting options, including surface or base pole with an M22 thread. The TL30BGRXXXNXQD is designed to operate in ambient air temperatures ranging from -40°C to +50°C and is rated with a degree of protection of IP65, UL type 4X, and UL type 13, making it suitable for various environments. Its cylindrical shape is complemented by a current consumption of 40mA and it supports 2 x digital inputs (12-30Vdc; NPN/PNP) for color control.

Related documents TL30BGRXXXNXQD Specs

TL30BGRXXXNXQD 206089.pdf
