Q7LMEB W/50 Banner Sensor Accessories

Q7LMEB W/50 on Powermatic Associates
Banner

Part#:Q7LMEB W/50

Manufacturer:Banner

Alt. Part#:86318

Product Lifecycle:Active

Get a quick Quote!

M-GAGE Q7LM Flat-Pak Sensor; Range: Varies depending on application; Input: 10-30 V dc; Output: Dual (Bipolar) NPN / PNP; 5 wire 26 gage shielded cable: polyurethane jacket 15 m (50 ft); Housing: Sealed With adhesive lined polyolefin heat shrink

About the manufacturer: Banner is one of the manufacturers that offers Sensor Accessories that you can order at Powermatic Associates site. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.

Check out the Q7LMEB W/50 Banner price in the box on the right side or send a quick quote.

Product Details

  • Weight
    508.02304 g
  • Country Of Origin
    MX

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

Q7LMEB W/50 Description

Banner Engineering Q7LMEB W/50 is a position sensor from the Q7LMEB series designed for vehicle detection. It operates within an ambient air temperature range of -40 to +70°C and features a 3-axis magneto-resistive-based detection mechanism. This Flat-Pak sensor is suitable for underground installation and comes pre-wired with a 50ft / 15m cable terminated with bare end flying leads. It offers a degree of protection rated at IP69K NEMA 6P and requires a supply voltage of 10Vdc-30Vdc, with nominal values of 12Vdc / 24Vdc. The rectangular-shaped sensor has an E-coated Aluminium housing and a thermoplastic end cap. It provides two digital outputs: one PNP transistor and one NPN transistor, with a response time of 20ms / 0.002 s.

Related documents Q7LMEB W/50 Specs

Q7LMEB W/50 172416.pdf

Manufacturer warranty

$636.00

Request a quote, and we will send availability within minutes.

Select Qty:

$636.00

$636.00 each

Average response time: 11 minutes

Worldwide Shipping and Delivery

Secure Payment Processing

Warranty

Responsive Customer Support
