Inductive Sensors - Turck

Turck NI12U-EM18-AP6X-0.2-RS4T is an inductive proximity sensor designed for a wide range of automation applications. This sensor operates within an ambient air temperature range of -30°C to +85°C and is equipped with a pre-wired 20cm / 8" pigtail cable that terminates with a 4-pin M12 Eurofast QD male connector. As part of the NI...-EM18 series, it features a stainless steel housing in an M18 partially threaded barrel shape, ensuring a degree of protection rated at IP67. The sensor operates with a supply voltage of 10-30Vdc, including nominal 12Vdc and 24Vdc, and offers a sensing distance of 12mm. It functions in a Normally Open (NO) operating mode and includes 1 x digital output (10-30Vdc; PNP) with protection functions against short-circuit (pulsed), overload, and reverse polarity. The thread size for this sensor is M18.

Turck NI5-EM12-AN6X-1-PSG3/S771 is an inductive proximity sensor designed for detecting the presence of metal objects without contact. This sensor operates within an ambient air temperature range of -25°C to +70°C and features a black moulded plug body for its design. It is pre-wired with a 1-meter (approximately 3 feet) pigtail cable that terminates with a 3-pin M8 Picofast snap-lock male connector, ensuring easy and secure connection. Part of the NI...-EM12 series, it boasts an IP67 degree of protection, making it suitable for use in environments where dust and water resistance are necessary. The sensor operates with a supply voltage range of 10-30Vdc, including nominal 12Vdc and 24Vdc, and is housed in a 1.4301 (304) stainless steel casing. Its M12 partially threaded barrel shape allows for straightforward installation. With a sensing distance of 5mm and operating in a Normally Open (NO) mode, it provides a single digital output (10-30Vdc; NPN). Additionally, it includes protection functions against short-circuit (pulsed), overload, and reverse polarity, enhancing its durability and operational integrity. The thread size for mounting is M12.

Turck BI5-M18E-AN6X-H1141 is an inductive proximity sensor belonging to the BI...-M18 series. This sensor features an extended barrel embeddable design with a chrome-plated brass housing and is pre-equipped with a 4-pin M12 Eurofast QD male connector. It operates on a supply voltage of 10-30Vdc, with nominal voltages of 12Vdc and 24Vdc. The sensor has a shape of an M18 partially threaded extended cylindrical/barrel and offers a degree of protection rated at IP67. It can operate at a maximum switching frequency of 1kHz / 1000Hz and has an ambient air temperature range for operation between -25°C and +70°C. The response time of the sensor is 8ms / 0.008 s, and it includes 1 x digital output (10-30Vdc; NPN; 200mA max.). The sensing distance is 5mm, and it features protection functions against short-circuit (pulsed), overload, and reverse polarity. The control circuit rated current is 200mA / 0.2 A, with a thread size of M18, and operates in a NO (Normally Open) mode.

Turck BI1-EG05-AN6X-0.2-PSG3/S771/CS10011 is an inductive proximity sensor from the BI...-EG05 series featuring a black moulded plug body that is embeddable. It operates with a supply voltage of 10-30Vdc, including nominal 12Vdc and 24Vdc, and is constructed with a stainless steel housing and a Polyamide (PA) sensing face. This sensor is designed with an M5 fully threaded barrel (Picoprox) shape and is pre-wired with a 20cm / 8" pigtail cable terminating in a 3-pin M8 Picofast snap-lock male connector. It offers a sensing distance of 1mm and includes a single digital output (10-30Vdc; NPN) for operation. The device is protected against short-circuit (pulsed), overload, and reverse polarity, ensuring its durability in various applications. With an IP67 degree of protection, it is suitable for operation in ambient air temperatures ranging from -25°C to +100°C. The operating mode for this sensor is Normally Open (NO), and it features an M5 thread size.

Inductive Sensor, Rated switching distance 4 mm, Non-flush, Threaded barrel, M12 x 1, Stainless steel, 1.4301, DC 4-wire, 10…30 VDC, Changeover contact, PNP output, M12 x 1 male connector

Inductive Sensor, Rated switching distance 2 mm, Cable length (L) 0.3 m, Flush, Rectangular, height 5.5 mm, Active face on top, Plastic, PP, DC 3-wire, 10…30 V DC, NC contact, NPN output, M8 × 1 connector

Inductive Sensor, Resistant to Magnetic Fields, Rated switching distance 10 mm, Flush, Threaded barrel, M30 x 1.5, Brass, PTFE-coated, , AC 2-wire, 20…250 VAC, DC 2-wire, 10…300 VDC, NO contact, 7/8" male connector

Inductive Sensor, Rated switching distance 5 mm, Cable length (L) 2 m, Non-flush, Threaded barrel, M12 x 1, Chrome-plated brass, DC 2-wire, nom. 8.2 VDC, Output acc. to DIN EN 60947-5-6 (NAMUR), Cable connection

Inductive Sensor, Rated switching distance 2 mm, Cable length (L) 7 m, Flush, Threaded barrel, M12 x 1, Plastic, PA12‐GF30, DC 3-wire, 10…30 VDC, NO contact, NPN output, TTL compatible, Cable connection

Inductive Sensor, For High Pressures, Rated switching distance 2 mm, Flush, Smooth barrel, stainless steel, 1.4305, Ø 12.7 mm, Housing, GD-Zn, chromated, , Admissible pressure static/dynamic 200/100 bar, Magnetic-resistant (insensitive to magnetic DC and AC fields), AC 2-wire, 20…250 VAC, DC 2-wire, 10…300 VDC, NC contact, 7/8" male connector
