Cable Accessories & Components - Turck

Accessory for 7/8, Closure cap, Threaded hand tighten, Male 7/8″ minifast Closure Cap, Mates to Female, Nitrile Gasket, Nitrile O-Ring

piconet stand-alone module for DeviceNet, 4 Analog Inputs 0(4)… 20 mA, , 4 analog inputs 0(4)…20 mA, Configuration interface, Parameterizable functions, Supported via I/O‐ASSISTANT 2, Direct connection to the fieldbus, Fibre-glass reinforced housing, Shock and vibration tested, Encapsulated module electronics, Metal connector, Degree of protection IP67

Actuator and Sensor Accessory, Closure cap, , Female M12 eurofast Closure Cap

IP-Link Optical Fiber, PUR Cable Jacket, Cable length (L) 0.2 m, POF optical fiber for IP‐Link, Fiber core PMMA 980 µm, Fiber insulation PE 2.2 mm, PUR jacket, 5.5 mm, Muting (650 nm), Muting (660 nm), Numeric aperture 0.5, Qualified for drag chain use, Flame-retardant, Halogen-free acc. to IEC60754, Excellent resistance to oil, grease, acids and alkaline solutions, Cable length: 0.2 m

Actuator and Sensor Accessory, Closure cap, , Female M12 eurofast Closure Cap

Actuator and Sensor Accessory, Closure cap, , Male M12 eurofast Closure Cap

Actuator and Sensor Accessory, Closure cap, , Female M12 eurofast Closure Cap

Turck BL67-WAS5-THERMO is a temperature sensor within the BL67 series, designed for temperature sensing and instrumentation. It features a Pt1000 for cold junction compensation, constructed with CuZn metal contacts and a PA plastic carrier/connector body. This sensor connects via a 5-pin M12 connector with screw-clamp connections and is rated with a degree of protection IP67. Its dimensions are 20 mm in height, 20 mm in depth, and 57.5 mm in width. The operational ambient air temperature range is from -25 to +90 °C.

Turck JBBS-57-E811 is a DeviceNet passive junction box within the JBBS series, designed with a blue/gray fiberglass housing and nickel-plated brass connectors. It features 8 x 5-pin M12 female connectors for drop connections and 1 x 5-pin 7/8" male connector plus 1 x 5-pin 7/8" female connector for bus in and out connections, respectively, facilitating a daisy-chain configuration. This junction box operates on a supply voltage of 11-30Vdc, with nominal values of 12Vdc and 24Vdc, and supports a surface or wall mounting mode. It has a net height of 172 mm, a width of 62 mm, and a depth of 37.3 mm. The JBBS-57-E811 is designed to operate within an ambient air temperature range of -40 to +75°C and is rated with a degree of protection of IP67, indicating its capability to withstand dust and water ingress.

Turck BCA-4HM-E223 is a connector (receptacle) designed specifically for 3/4" form 8 or mark 9 conduits. It features a stainless steel receptacle and a housing made of fiberglass reinforced nylon. This part is equipped with 2 x 4-pin M12 connectors and supports the HART communication protocol. It also functions as a HART cover wall-plate adapter. The BCA-4HM-E223 offers a degree of protection rated at IP67, indicating its capability to withstand dust and water ingress.
