Servo Motor Drives on Powermatic Associates

UMD-0001B-B5 Unitronics - B5 Series Servo Drive, 1 Phase, 220V, 0.1kW, CANopen

UMD-0010E-E5-S Unitronics - E5-S Series Servo Drive, 3 Phase, 400V, 1kW, EtherCAT, STO

UMD-0015E-E5-S Unitronics - E5-S Series Servo Drive, 3 Phase, 400V, 1.5kW, EtherCAT, STO

UMD-0020C-E5-S Unitronics - E5-S Series Servo Drive, 3 Phase, 220V, 2kW, EtherCAT, STO

UMD-0050E-E5-S Unitronics - E5-S Series Servo Drive, 3 Phase, 400V, 5.5kW, EtherCAT, STO

Schneider Electric LXM26DU20M3X is an AC servo drive within the Servo drives sub-range, designed with forced cooling, Pulse Train Output (PTO), and a 7-segment display. It features spring-clamp connections, an RJ45 connector, a 50-pin D-sub male connector, and a 6-pin male connector for versatile connectivity. The drive operates on Modbus RTU communication protocol, supports a rated current of 12A, and is compatible with a supply voltage of 200Vac-240Vac (220Vac / 230Vac). It is designed for surface mounting, with dimensions of 194.5 mm in height, 197 mm in width, and 62 mm in depth. The operating ambient air temperature range is 0 to +55°C, and it has an IP20 degree of protection. The drive accommodates a single-phase input (2P) or three-phase input (3P) network type, includes 2 x analog outputs (-8...+8Vdc / 10mA / 1kΩ / 12-bits resolution), 2 x digital inputs (Sink / Source; PNP / NPN), 8 x digital inputs (24Vdc), and 5 x digital outputs (24Vdc). It also features 2 x analog inputs (-10...+10Vdc / 10kΩ / 12-bits resolution), operates within a frequency range of 47.5-63Hz, and has a rated active power of 2kW / 2000W. The device is designed for storage in ambient air temperatures ranging from -25 to +65°C.

Schneider Electric LXM23DU30M3X is an AC servo drive within the Servo drives sub-range, designed with forced cooling and spring-clamp connections alongside an RJ45 connector. It features a comprehensive suite of protection functions including reverse polarity, short-circuit, overcurrent, overvoltage, undervoltage, overheating, overload, and overspeed protections for the motor. This servo drive has a rated current of 19.4A and operates on a supply voltage of 200Vac-240Vac, specifically 220Vac or 230Vac. It is designed for surface mounting, with dimensions of 225 mm in height, 114 mm in width, and 195 mm in depth. The operating ambient air temperature range is 0 to +55°C, and it has an IP20 degree of protection. The LXM23DU30M3X supports both single-phase (2P) and three-phase (3P) network types, includes 8 digital inputs and 5 digital outputs, all 24Vdc, and has 2 analog inputs ranging from -10 to +10Vdc. The frequency range supported is 47.5-63Hz, and it has a rated active power of 3kW or 3000W. Storage temperature tolerance ranges from -25 to +65°C.

Schneider Electric LXM26DU07M3X is an AC servo drive within the Servo drives sub-range, designed with forced cooling, Pulse Train Output (PTO), and a 7-segment display. It features spring-clamp connections, an RJ45 connector, a 50-pin D-sub male connector, and a 6-pin male connector for versatile connectivity. The drive operates on Modbus RTU communication protocol, with a rated current of 4.5A and a supply voltage range of 200Vac-240Vac, accommodating both 220Vac and 230Vac. It is designed for surface mounting, with dimensions of 173.2 mm in height, 152.7 mm in width, and 55 mm in depth. The operating ambient air temperature range is 0 to +55°C, and it has an IP20 degree of protection. The network type includes both single-phase input (2P) and three-phase input (3P). It offers 2 analog outputs with a -8 to +8Vdc range, 10mA, 1kΩ, and 12-bits resolution, alongside 2 and 8 digital inputs for Sink/Source, PNP/NPN, and 24Vdc respectively, and 5 digital outputs of 24Vdc. The frequency range is 47.5-63Hz, with 2 analog inputs at -10 to +10Vdc, 10kΩ, and 12-bits resolution. The rated active power is 0.75kW or 750W, and it can be stored in temperatures ranging from -25 to +65°C.

Schneider Electric LXM23CU30M3X is an AC servo drive within the Servo drives sub-range, designed with forced cooling and spring-clamp connections alongside an RJ45 connector. It features comprehensive protection functions including reverse polarity, short-circuit, overcurrent, overvoltage, undervoltage, overheating, overload, and overspeed protections for the motor. This servo drive has a rated current of 19.4A and operates on a supply voltage of 200Vac-240Vac, specifically designed for 220Vac or 230Vac. It is intended for surface mounting, with dimensions of 245 mm in height, 276 mm in width, and 110 mm in depth. The operating ambient air temperature range is 0 to +55°C, and it has an IP20 degree of protection. Connectivity options include 8 digital inputs (24Vdc / NPN / PNP), 5 digital outputs (24Vdc), and 2 analog inputs (-10 to +10Vdc / 10kΩ). It supports both single-phase (2P) and three-phase (3P) network types, operates at a frequency of 47.5-63Hz, and delivers a rated active power of 3kW / 3000W. The device is also designed to withstand storage temperatures ranging from -25 to +65°C.

Schneider Electric LXM23CU04M3X is an AC servo drive within the Servo drives sub-range, designed with a natural cooling system. It features spring-clamp connections and an RJ45 connector for connectivity. This model is equipped with multiple protection functions including reverse polarity, short-circuit, overcurrent, overvoltage, undervoltage, overheating, overload, and overspeed protections for the motor. It has a rated current of 2.6A and operates on a supply voltage of 200Vac-240Vac, specifically 220Vac / 230Vac. The LXM23CU04M3X is designed for surface mounting, with dimensions of 162 mm in height, 210 mm in width, and 75 mm in depth. It operates efficiently within an ambient air temperature range of 0 to +55 °C and is designed for storage in temperatures ranging from -25 to +65 °C. This servo drive boasts an IP20 degree of protection and supports both single-phase (2P) and three-phase (3P) network types. It includes 8 digital inputs (24Vdc / NPN / PNP), 5 digital outputs (24Vdc), and 2 analog inputs (-10...+10Vdc / 10kΩ), with a frequency range of 47.5-63Hz. The rated active power is 0.4kW or 400W.
