Pilz PILZ-570502 is a magnetic transponder safety gate system designed for door locking applications. It operates within an ambient air temperature range of -25 to +55 °C and features a standard actuator with a fully coded switch and basic software. This part is equipped with a 5-pin M12 male connector for its connection type and has dimensions of W45mm x H122mm x L44mm. It boasts a degree of protection rated at IP67, making it suitable for various environmental conditions. The supply voltage required for operation is 24Vdc, and it is constructed from PBT material. The sensing distance of the device is 15mm (Sao), with a power consumption of 4.8 W. Additionally, it includes 2 x digital outputs (OSSD; 500mA) and 1 x digital input (24Vdc; 5mA) for enhanced functionality.
Quick Quote
Pilz PILZ-570884 is a door lock actuator designed for safety gate systems with a coded switch. It features standard actuation and operates within an ambient air temperature range of -20 to +55°C. The dimensions of this part are W195mm x H110mm x L108mm, and it offers a degree of protection rated at IP65.
Quick Quote
Pilz PILZ-570880 is a door lock designed for handle operation, featuring a complete transponder safety gate system. It includes three illuminated push-buttons for various control functions, one non-illuminated push-button for accessing and interlocking the safety gate, and an emergency stop push-button equipped with a color cap, escape release bar, and an actuator suitable for both right or left hinged gates. This unit operates within an ambient air temperature range of -20 to +55 °C and is designed with a guard locking safe interlock, fully-coded switch, three illuminated push-buttons, one non-illuminated push-button, and one emergency stop switch with an actuator. It offers plug-in/detachable spring-loaded terminal connections for ease of installation, measures W200mm x H555mm x L108mm, and is protected to IP54 standards against dust and splashing water. The PILZ-570880 requires a 24Vdc supply voltage, consumes 2W of power, operates in a power-to-unlock mode, and features 2 x digital outputs (OSSD; semiconductor outputs; 500mA) and 2 x digital inputs (safe range inputs; 1.5A; 150ms) for comprehensive control and safety integration.
Quick Quote
Pilz PILZ-570831 is a door lock designed for handle operation, featuring a transponder safety gate system. It includes an illuminated push-button for activating the safety gate, a key button for accessing and interlocking the safety gate, a three-position key switch, an additional illuminated push-button, and a blind cover with a 5-pin M12 connection for connecting with an enable switch. This part operates within an ambient air temperature range of -20 to +55 °C and is designed with guard locking, a safe interlock coded switch, two illuminated push buttons, one key-operated push button, one key switch, and one blind cover switch part only. It offers plug-in/detachable spring-loaded terminal connections and a 5-pin M12 connector. The dimensions are W46.5mm x H568mm x L74.5mm, with a degree of protection of IP54. It requires a supply voltage of 24Vdc and operates in a power-to-unlock mode. The device includes 2 x digital outputs (OSSD; semiconductor outputs; 500mA) and 2 x digital inputs (safe range inputs; 1.5A; 150ms).
Quick Quote
Pilz PILZ-570821 is a door lock designed for handle operation, featuring a complete transponder safety gate system. It includes three illuminated push-buttons, one key button for accessing and interlocking the safety gate, and one blind cover sensing device equipped with pushbuttons, color cap, and escape release bar and actuator suitable for both right or left hinged gates. This product operates within an ambient air temperature range of -20 to +55 °C and is designed with a guard locking safe interlock coded switch, three illuminated push buttons, one key switch, one blind cover switch plus actuator. It offers plug-in/detachable spring-loaded terminal connections for ease of installation. The dimensions are W200mm x H555mm x L108mm, with a degree of protection rated at IP54, ensuring protection against dust and splashing water. It requires a supply voltage of 24Vdc and has a power consumption of 2W. The operating mode is power-to-unlock, and it features 2 x digital outputs (OSSD; semiconductor outputs; 500mA) and 2 x digital inputs (safe range inputs; 1.5A; 150ms) for connectivity and control.
Quick Quote
Pilz PILZ-570819 is a door lock designed for handle operation, featuring a complete transponder safety gate system. It includes three illuminated push-buttons for various controls, one non-illuminated push-button for accessing and interlocking the safety gate, and one blind cover sensing device equipped with pushbuttons, color cap, and an escape release bar. The actuator is adaptable for both right or left hinged gates. This unit operates within an ambient air temperature range of -20 to +55 °C and is designed with a guard locking safe interlock coded switch, incorporating three illuminated push-buttons, one non-illuminated push-button, and one blind cover switch plus actuator. It offers plug-in/detachable spring-loaded terminal connections for ease of installation, with dimensions of W200mm x H555mm x L108mm. The PILZ-570819 is IP54 rated, indicating a degree of protection against dust and splashing water. It requires a 24Vdc supply voltage, has a power consumption of 2W, and operates in a power-to-unlock mode. For interfacing, it features 2 x digital outputs (OSSD; semiconductor outputs; 500mA) and 2 x digital inputs (safe range inputs; 1.5A; 150ms).
Quick Quote
Pilz PILZ-570817 is a door lock designed for handle operation, featuring a complete transponder safety gate system. It includes an illuminated push-button for activating the safety gate, a key button for accessing and interlocking the safety gate, three additional illuminated push-buttons, and a section stop sensing device equipped with a push-button, color cap, escape release bar, and an actuator suitable for both right or left hinged gates. This product operates within an ambient air temperature range of -20 to +55 °C and is designed with a guard locking safe interlock, coded switch, three illuminated push buttons, one section stop push button, one key switch switch, and an actuator. It offers plug-in/detachable spring-loaded terminal connections and measures W200mm x H555mm x L108mm. The PILZ-570817 has an IP54 degree of protection, requires a 24Vdc supply voltage, and consumes 2W of power. It operates in a power-to-unlock mode and features 2 x digital outputs (OSSD; semiconductor outputs; 500mA) and 2 x digital inputs (safe range inputs; 1.5A; 150ms).
Quick Quote
Pilz PILZ-570813 is a door lock designed for handle operation, featuring a complete transponder safety gate system. It includes a variety of functions such as an illuminated push-button for activating the safety gate, a key button for accessing and interlocking the safety gate, three additional illuminated push-buttons, and an E-stop sensing device equipped with pushbuttons, color cap, escape release bar, and an actuator suitable for both right or left hinged gates. This product operates within an ambient air temperature range of -20 to +55 °C and is designed with guard locking safe interlock, coded switch, three illuminated push buttons, one E-stop, one key switch, plus an actuator. It offers plug-in/detachable spring-loaded terminal connections for ease of installation. The dimensions of this part are W200mm x H555mm x L108mm, and it has an IP54 degree of protection against dust and water splashes. The supply voltage required is 24Vdc with a power consumption of 2W, operating in a power-to-unlock mode. It features 2 x digital outputs (OSSD; semiconductor outputs; 500mA) and 2 x digital inputs (safe range inputs; 1.5A; 150ms) for connectivity and integration into safety systems.
Quick Quote
Pilz PILZ-570808 is a door lock designed for handle operation, featuring a transponder safety gate system. It includes three push-buttons: one illuminated for activating the safety gate, one non-illuminated for accessing and interlocking the safety gate, and one blind cover serving as a sensing device with push-button for spare parts. This product operates within an ambient air temperature range of -20 to +55 °C and is designed with a guard locking safe interlock, coded switch, one illuminated push button, one non-illuminated push button, and one blind cover switch part only. It offers plug-in/detachable spring-loaded terminal connections for ease of installation. The dimensions are W46.5mm x H465mm x L74.5mm, with a degree of protection rated at IP54. It requires a 24Vdc supply voltage, has a power consumption of 2 W, and operates in a power-to-unlock mode. Additionally, it features 2 x digital outputs (OSSD; semiconductor outputs; 500mA) and 2 x digital inputs (safe range inputs; 1.5A; 150ms) for enhanced functionality.
Quick Quote
Pilz PILZ-570802 is a door lock designed for handle operation, featuring a complete transponder safety gate system. It includes three push-buttons: an illuminated button for activating the safety gate, a non-illuminated button for accessing and interlocking the safety gate, and an emergency stop button equipped with color caps and an escape release bar, suitable for both right or left hinged gates. This unit operates within an ambient air temperature range of -20 to +55 °C and is designed with a guard locking safe interlock, coded switch, one illuminated push button, one non-illuminated push button, and one section stop push button switch plus actuator. It offers plug-in/detachable spring-loaded terminal connections for ease of installation. The dimensions of this device are W200mm x H465mm x L108mm, and it is protected to a degree of IP54 against dust and splashing water. The supply voltage required is 24Vdc with a power consumption of 2W, operating in a power-to-unlock mode. It features 2 x digital outputs (OSSD; semiconductor outputs; 500mA) and 2 x digital inputs (safe range inputs; 1.5A; 150ms) for comprehensive control and safety integration.
Quick Quote
Item | Manufacturer | Price | Stock | Delivery | |
---|---|---|---|---|---|
PILZ-570502 Pilz PILZ-570502 is a magnetic transponder safety gate system designed for door locking applications. It operates within an ambient air temperature range of -25 to +55 °C and features a standard actuator with a fully coded switch and basic software. This part is equipped with a 5-pin M12 male connector for its connection type and has dimensions of W45mm x H122mm x L44mm. It boasts a degree of protection rated at IP67, making it suitable for various environmental conditions. The supply voltage required for operation is 24Vdc, and it is constructed from PBT material. The sensing distance of the device is 15mm (Sao), with a power consumption of 4.8 W. Additionally, it includes 2 x digital outputs (OSSD; 500mA) and 1 x digital input (24Vdc; 5mA) for enhanced functionality. | Pilz | Quick Quote | |||
PILZ-570884 Pilz PILZ-570884 is a door lock actuator designed for safety gate systems with a coded switch. It features standard actuation and operates within an ambient air temperature range of -20 to +55°C. The dimensions of this part are W195mm x H110mm x L108mm, and it offers a degree of protection rated at IP65. | Pilz | Quick Quote | |||
PILZ-570880 Pilz PILZ-570880 is a door lock designed for handle operation, featuring a complete transponder safety gate system. It includes three illuminated push-buttons for various control functions, one non-illuminated push-button for accessing and interlocking the safety gate, and an emergency stop push-button equipped with a color cap, escape release bar, and an actuator suitable for both right or left hinged gates. This unit operates within an ambient air temperature range of -20 to +55 °C and is designed with a guard locking safe interlock, fully-coded switch, three illuminated push-buttons, one non-illuminated push-button, and one emergency stop switch with an actuator. It offers plug-in/detachable spring-loaded terminal connections for ease of installation, measures W200mm x H555mm x L108mm, and is protected to IP54 standards against dust and splashing water. The PILZ-570880 requires a 24Vdc supply voltage, consumes 2W of power, operates in a power-to-unlock mode, and features 2 x digital outputs (OSSD; semiconductor outputs; 500mA) and 2 x digital inputs (safe range inputs; 1.5A; 150ms) for comprehensive control and safety integration. | Pilz | Quick Quote | |||
PILZ-570831 Pilz PILZ-570831 is a door lock designed for handle operation, featuring a transponder safety gate system. It includes an illuminated push-button for activating the safety gate, a key button for accessing and interlocking the safety gate, a three-position key switch, an additional illuminated push-button, and a blind cover with a 5-pin M12 connection for connecting with an enable switch. This part operates within an ambient air temperature range of -20 to +55 °C and is designed with guard locking, a safe interlock coded switch, two illuminated push buttons, one key-operated push button, one key switch, and one blind cover switch part only. It offers plug-in/detachable spring-loaded terminal connections and a 5-pin M12 connector. The dimensions are W46.5mm x H568mm x L74.5mm, with a degree of protection of IP54. It requires a supply voltage of 24Vdc and operates in a power-to-unlock mode. The device includes 2 x digital outputs (OSSD; semiconductor outputs; 500mA) and 2 x digital inputs (safe range inputs; 1.5A; 150ms). | Pilz | Quick Quote | |||
PILZ-570821 Pilz PILZ-570821 is a door lock designed for handle operation, featuring a complete transponder safety gate system. It includes three illuminated push-buttons, one key button for accessing and interlocking the safety gate, and one blind cover sensing device equipped with pushbuttons, color cap, and escape release bar and actuator suitable for both right or left hinged gates. This product operates within an ambient air temperature range of -20 to +55 °C and is designed with a guard locking safe interlock coded switch, three illuminated push buttons, one key switch, one blind cover switch plus actuator. It offers plug-in/detachable spring-loaded terminal connections for ease of installation. The dimensions are W200mm x H555mm x L108mm, with a degree of protection rated at IP54, ensuring protection against dust and splashing water. It requires a supply voltage of 24Vdc and has a power consumption of 2W. The operating mode is power-to-unlock, and it features 2 x digital outputs (OSSD; semiconductor outputs; 500mA) and 2 x digital inputs (safe range inputs; 1.5A; 150ms) for connectivity and control. | Pilz | Quick Quote | |||
PILZ-570819 Pilz PILZ-570819 is a door lock designed for handle operation, featuring a complete transponder safety gate system. It includes three illuminated push-buttons for various controls, one non-illuminated push-button for accessing and interlocking the safety gate, and one blind cover sensing device equipped with pushbuttons, color cap, and an escape release bar. The actuator is adaptable for both right or left hinged gates. This unit operates within an ambient air temperature range of -20 to +55 °C and is designed with a guard locking safe interlock coded switch, incorporating three illuminated push-buttons, one non-illuminated push-button, and one blind cover switch plus actuator. It offers plug-in/detachable spring-loaded terminal connections for ease of installation, with dimensions of W200mm x H555mm x L108mm. The PILZ-570819 is IP54 rated, indicating a degree of protection against dust and splashing water. It requires a 24Vdc supply voltage, has a power consumption of 2W, and operates in a power-to-unlock mode. For interfacing, it features 2 x digital outputs (OSSD; semiconductor outputs; 500mA) and 2 x digital inputs (safe range inputs; 1.5A; 150ms). | Pilz | Quick Quote | |||
PILZ-570817 Pilz PILZ-570817 is a door lock designed for handle operation, featuring a complete transponder safety gate system. It includes an illuminated push-button for activating the safety gate, a key button for accessing and interlocking the safety gate, three additional illuminated push-buttons, and a section stop sensing device equipped with a push-button, color cap, escape release bar, and an actuator suitable for both right or left hinged gates. This product operates within an ambient air temperature range of -20 to +55 °C and is designed with a guard locking safe interlock, coded switch, three illuminated push buttons, one section stop push button, one key switch switch, and an actuator. It offers plug-in/detachable spring-loaded terminal connections and measures W200mm x H555mm x L108mm. The PILZ-570817 has an IP54 degree of protection, requires a 24Vdc supply voltage, and consumes 2W of power. It operates in a power-to-unlock mode and features 2 x digital outputs (OSSD; semiconductor outputs; 500mA) and 2 x digital inputs (safe range inputs; 1.5A; 150ms). | Pilz | Quick Quote | |||
PILZ-570813 Pilz PILZ-570813 is a door lock designed for handle operation, featuring a complete transponder safety gate system. It includes a variety of functions such as an illuminated push-button for activating the safety gate, a key button for accessing and interlocking the safety gate, three additional illuminated push-buttons, and an E-stop sensing device equipped with pushbuttons, color cap, escape release bar, and an actuator suitable for both right or left hinged gates. This product operates within an ambient air temperature range of -20 to +55 °C and is designed with guard locking safe interlock, coded switch, three illuminated push buttons, one E-stop, one key switch, plus an actuator. It offers plug-in/detachable spring-loaded terminal connections for ease of installation. The dimensions of this part are W200mm x H555mm x L108mm, and it has an IP54 degree of protection against dust and water splashes. The supply voltage required is 24Vdc with a power consumption of 2W, operating in a power-to-unlock mode. It features 2 x digital outputs (OSSD; semiconductor outputs; 500mA) and 2 x digital inputs (safe range inputs; 1.5A; 150ms) for connectivity and integration into safety systems. | Pilz | Quick Quote | |||
PILZ-570808 Pilz PILZ-570808 is a door lock designed for handle operation, featuring a transponder safety gate system. It includes three push-buttons: one illuminated for activating the safety gate, one non-illuminated for accessing and interlocking the safety gate, and one blind cover serving as a sensing device with push-button for spare parts. This product operates within an ambient air temperature range of -20 to +55 °C and is designed with a guard locking safe interlock, coded switch, one illuminated push button, one non-illuminated push button, and one blind cover switch part only. It offers plug-in/detachable spring-loaded terminal connections for ease of installation. The dimensions are W46.5mm x H465mm x L74.5mm, with a degree of protection rated at IP54. It requires a 24Vdc supply voltage, has a power consumption of 2 W, and operates in a power-to-unlock mode. Additionally, it features 2 x digital outputs (OSSD; semiconductor outputs; 500mA) and 2 x digital inputs (safe range inputs; 1.5A; 150ms) for enhanced functionality. | Pilz | Quick Quote | |||
PILZ-570802 Pilz PILZ-570802 is a door lock designed for handle operation, featuring a complete transponder safety gate system. It includes three push-buttons: an illuminated button for activating the safety gate, a non-illuminated button for accessing and interlocking the safety gate, and an emergency stop button equipped with color caps and an escape release bar, suitable for both right or left hinged gates. This unit operates within an ambient air temperature range of -20 to +55 °C and is designed with a guard locking safe interlock, coded switch, one illuminated push button, one non-illuminated push button, and one section stop push button switch plus actuator. It offers plug-in/detachable spring-loaded terminal connections for ease of installation. The dimensions of this device are W200mm x H465mm x L108mm, and it is protected to a degree of IP54 against dust and splashing water. The supply voltage required is 24Vdc with a power consumption of 2W, operating in a power-to-unlock mode. It features 2 x digital outputs (OSSD; semiconductor outputs; 500mA) and 2 x digital inputs (safe range inputs; 1.5A; 150ms) for comprehensive control and safety integration. | Pilz | Quick Quote |
