TX800 HMI/PLC Product Series, Quad-Core IOT Gateway — CODESYS V3 PLC with WEB VISU, , 2 separated RJ45 Ethernet ports with 10/100 Mbit, 1 serial interface (RS232, RS485, RS422), 1 USB host port, 1 SD card slot, 1 expansion module slot

Banner DX80DR2M-H6 NB - MultiHop 2.4 GHz 65 mW IP67; Internal Battery (not included) External Antenna; 1-wire Serial Interface

Banner DX80DR2M-H3E NB - MultiHop 2.4 GHz 65 mW IP65; Internal Battery (not included) External Antenna RS232; Inputs: 2 Discrete 4 Thermocouple; Outputs: 2 Discrete

Banner Engineering DX80SR2ME-H is a gateway designed for surface mounting with a polycarbonate housing, polycarbonate rotary dial cover, polyester labels, EDPM rubber cover gasket, and nitrile rubber. It operates within an ambient air temperature range of -40 to +85°C and offers a degree of protection rated at IP67 NEMA 6. This rectangular-shaped device has dimensions of H41.3mm x W80.14mm x D80.14mm and features a visual position indicator with red/green LED for radio status. It operates on a transmission frequency of 2400 MHz and is part of the SureCross DX80 series. The design includes 2 x bi-color LEDs compliant with the European Radio Equipment Directive (RED) and utilizes Frequency Hopping Spread Spectrum (FHSS) technology. It offers screw connections and an RP-SMA connector for connectivity, requires a supply voltage of 10-30Vdc (12Vdc-24Vdc nom.), and supports communication protocols including RS-485, RS-232, and Modbus RTU. Operating on a frequency of 2.4GHz ISM band at 65mW, it can achieve a maximum transmission distance of 3.2km at nominal emission power.

a

Banner Engineering DX80DR2M-H3E-NB-KR is a gateway designed for surface mounting with a polycarbonate housing, polycarbonate rotary dial cover, polyester labels, EDPM rubber cover gasket, and nitrile rubber, ensuring durability in various environments. It operates within an ambient air temperature range of -40 to +85°C and offers a degree of protection rated at IP65 and NEMA 4X. The dimensions of this rectangular-shaped gateway are H59.8mm x W126.7mm x D117.4mm. It features 2 digital outputs (30Vdc; NMOS; 1A), 4 analog inputs for Thermocouples with 24-bit A/D conversion, and 1 analog input for a Thermistor 10kΩ. The DX80DR2M-H3E-NB-KR operates on a transmission frequency of 2400 MHz and includes 2 digital inputs (30Vdc 3mA; NPN). It is equipped with MultiHop data radio functionality, falls under the MultiHop Modbus IO data radios sub-range, and is designed with 2 buttons, 2 bi-color LEDs for Ex e II applications (battery not included) for South Korea, and utilizes FHSS (Frequency Hopping Spread Spectrum) technology. The connection type is a wiring chamber with screw-clamp connections and 2 x 1/2" NPT threaded cable accesses alongside an RP-SMA connector. It requires a supply voltage of 10-30Vdc (12Vdc-24Vdc nom.), supports RS-232 Modbus TCP communication protocol, operates on the 2.4GHz ISM band at 65mW, and can achieve a maximum transmission distance of 3.2km at nominal emission power.

Panasonic SC-GU3-04 is a communications unit designed to facilitate communication for CC-Link IE Field and CC-Link networks.

Panasonic SL-VMEL-Q is a communications unit designed for direct hook-up to the MELSEC-Q series bus controller.

Panasonic SL-VGU1-C is a communications unit designed as an S-LINK V gateway for enabling connection to a CC-LINK network.

Pilz PILZ-311601 is a gateway protocol converter designed for DIN rail mounting, facilitating potential isolation between CANopen and system voltage as well as between Modbus and system voltage with functional insulation and a rated surge voltage of 500V. It operates within an ambient air temperature range of 0 to +60°C and offers a degree of protection IP20. The device is equipped with a 9-pin D-sub male connector for CANopen peripherals and 8 x RJ45 connectors for Modbus server connections, supporting plug-in/detachable screw or spring-loaded terminal connections. The supply voltage required is 24Vdc, housed in a PC material with dimensions of 96mm in height, 22.5mm in width, and 114.3mm in depth. It supports communication protocols Modbus TCP and CANopen, with a cross-section range for wiring and operates in Auto-MDIX mode for Modbus. The storage temperature range is -25 to +70°C, featuring protection functions such as galvanic isolation and potential isolation. The response time is set at 20ms for supply interruption before de-energization and 32000ms for the default keep alive time. Transmission speeds vary from 10kBit/s to 1MBit/s for CANopen and 10MBit/s to 100MBit/s for Modbus.
