Wago 2002-475 is a busbar (comb) designed for use in electrical installations and panel building. It features an insulated staggered jumper with a 5-way design, suitable for a 5-poles (5P) configuration. This part is rated for a current of 25A and is compatible with the TOPJOB S series. The net width of the part corresponds to the 5-poles configuration, and it has a power consumption color coded as Light Gray. The residual current sensitivity is specified with a width of 24.7mm, and it is designed to operate at a voltage of 400 V within network frequencies associated with the TOPJOB S series.
100 in stock
24 hours
Wago 2002-402 is an insulated push-in type comb-style jumper bar designed for use in the TOPJOB S series. It features a 2-way design with a rated current of 25A and is compatible with a network frequency specific to the TOPJOB S series. The part has a net width for 2-poles (2P) and is presented in light gray. Its dimensions are H4.1mm x W8.6mm x D19mm, and it can withstand a voltage up to 800V.
40 in stock
24 hours
Red Lion C48CS003 is a single preset digital counter within the C48 series, designed to fit a 1/16 DIN (48x48mm) enclosure. It operates on a supply voltage range of 85-250Vac, including specific values such as 100Vac, 110Vac, 120Vac, 200Vac, 208Vac, 220Vac, 230Vac, and 240Vac, and also supports a DC supply voltage of 11-14Vdc, specifically 12Vdc. The dimensions of this counter are standardized to 1/16 DIN, measuring W48mm x H48mm (1.89" x 1.89"). It offers a degree of protection rated at IP65 NEMA 4X, suitable for flush or door mounting. The C48CS003 features 1 high-speed digital input (12kHz; Sink/Source) labeled INPUT A, an additional digital input (Sink/Source) designated as USER INPUT 1, and a third digital input (Sink/Source) that can function as input B or USER INPUT 1. For output, it provides 1 digital output (NPN) and 1 digital output (contact type NO).
1 in stock
24 hours
Schneider Electric LC1D150G7 is a magnetic contactor from the Deca sub-range, designed with screw connections and three poles (3P; 3NO). It has a rated current of 200A for AC-1 and 150A for 440Vac in AC-3 conditions. This contactor is suitable for DIN rail mounting and has a net width of 120 mm. It offers a degree of protection rated at IP20 and operates with a control voltage (AC) range of 96-138Vac (120Vac nominal; 50Hz/60Hz; 0.8...1.15 x Uc). The rated operating voltage (Ue) is up to 1000 V, and it features 1 normally open (NO) auxiliary contact. The rated impulse voltage (Uimp) is 8 kV. Its rated active power ranges from 40kW at 220-230Vac to 100kW at 660-690Vac in AC-3 conditions. Additionally, it includes 1 normally closed (NC) auxiliary contact with contacts type of 1NO+1NC instantaneous aux. The rated power in horsepower (HP) varies from 40HP at 200-208Vac to 125HP at 575-600Vac for 3-phase, 50Hz/60Hz, UL/CSA. The mechanical durability of the LC1D150G7 is rated at 8 million operations at no load, and its electrical durability with load is 850,000 operations. The rated voltage (AC) for phase-to-phase connections is 1000 V.
10 in stock
24 hours
Square D by Schneider Electric QO3155237 is a Miniature Circuit Breaker (MCB) designed for plug-in mounting. It features a rated current of 15A and accommodates a plug-in connection type. This MCB is suitable for use with a voltage rating of 48Vdc and 120V/240V AC, supporting a cross-section of 14-8AWG for 1 aluminum or copper cable. It is a 3 Pole circuit breaker with a short circuit breaking rating of 10kA at 240Vac and 5kA at 48Vdc. The terminals are designed for ring tongue connections.
23 in stock
24 hours
Item | Manufacturer | Price | Stock | Delivery | |
---|---|---|---|---|---|
S802S-B6 ABB Control - S802S-B6 | ABB Control | $118.47 | 2 in stock | 24 hours | |
2002-475 Wago 2002-475 is a busbar (comb) designed for use in electrical installations and panel building. It features an insulated staggered jumper with a 5-way design, suitable for a 5-poles (5P) configuration. This part is rated for a current of 25A and is compatible with the TOPJOB S series. The net width of the part corresponds to the 5-poles configuration, and it has a power consumption color coded as Light Gray. The residual current sensitivity is specified with a width of 24.7mm, and it is designed to operate at a voltage of 400 V within network frequencies associated with the TOPJOB S series. | WAGO | $2.38 | 100 in stock | 24 hours | |
2002-402 Wago 2002-402 is an insulated push-in type comb-style jumper bar designed for use in the TOPJOB S series. It features a 2-way design with a rated current of 25A and is compatible with a network frequency specific to the TOPJOB S series. The part has a net width for 2-poles (2P) and is presented in light gray. Its dimensions are H4.1mm x W8.6mm x D19mm, and it can withstand a voltage up to 800V. | WAGO | $0.57 | 40 in stock | 24 hours | |
S1112 Lapp - S1112 | Lapp | $2.97 | 98 in stock | 24 hours | |
601403 Lapp - 601403 | Lapp | $2.58 | 44 in stock | 24 hours | |
DF101 Schneider Electric - DF101 | Schneider Electric | $10.20 | 10 in stock | 24 hours | |
C48CS003 Red Lion C48CS003 is a single preset digital counter within the C48 series, designed to fit a 1/16 DIN (48x48mm) enclosure. It operates on a supply voltage range of 85-250Vac, including specific values such as 100Vac, 110Vac, 120Vac, 200Vac, 208Vac, 220Vac, 230Vac, and 240Vac, and also supports a DC supply voltage of 11-14Vdc, specifically 12Vdc. The dimensions of this counter are standardized to 1/16 DIN, measuring W48mm x H48mm (1.89" x 1.89"). It offers a degree of protection rated at IP65 NEMA 4X, suitable for flush or door mounting. The C48CS003 features 1 high-speed digital input (12kHz; Sink/Source) labeled INPUT A, an additional digital input (Sink/Source) designated as USER INPUT 1, and a third digital input (Sink/Source) that can function as input B or USER INPUT 1. For output, it provides 1 digital output (NPN) and 1 digital output (contact type NO). | Red Lion | $173.00 | 1 in stock | 24 hours | |
559689 Insulator, F-F, ISO 2-1/2”, 3/8-16 | Eriflex | $5.46 | 6 in stock | 24 hours | |
LC1D150G7 Schneider Electric LC1D150G7 is a magnetic contactor from the Deca sub-range, designed with screw connections and three poles (3P; 3NO). It has a rated current of 200A for AC-1 and 150A for 440Vac in AC-3 conditions. This contactor is suitable for DIN rail mounting and has a net width of 120 mm. It offers a degree of protection rated at IP20 and operates with a control voltage (AC) range of 96-138Vac (120Vac nominal; 50Hz/60Hz; 0.8...1.15 x Uc). The rated operating voltage (Ue) is up to 1000 V, and it features 1 normally open (NO) auxiliary contact. The rated impulse voltage (Uimp) is 8 kV. Its rated active power ranges from 40kW at 220-230Vac to 100kW at 660-690Vac in AC-3 conditions. Additionally, it includes 1 normally closed (NC) auxiliary contact with contacts type of 1NO+1NC instantaneous aux. The rated power in horsepower (HP) varies from 40HP at 200-208Vac to 125HP at 575-600Vac for 3-phase, 50Hz/60Hz, UL/CSA. The mechanical durability of the LC1D150G7 is rated at 8 million operations at no load, and its electrical durability with load is 850,000 operations. The rated voltage (AC) for phase-to-phase connections is 1000 V. | Schneider Electric | $696.00 | 10 in stock | 24 hours | |
QO3155237 Square D by Schneider Electric QO3155237 is a Miniature Circuit Breaker (MCB) designed for plug-in mounting. It features a rated current of 15A and accommodates a plug-in connection type. This MCB is suitable for use with a voltage rating of 48Vdc and 120V/240V AC, supporting a cross-section of 14-8AWG for 1 aluminum or copper cable. It is a 3 Pole circuit breaker with a short circuit breaking rating of 10kA at 240Vac and 5kA at 48Vdc. The terminals are designed for ring tongue connections. | Schneider Electric | $319.68 | 23 in stock | 24 hours |
