Contactors

Schneider Electric LC1DT80AX7 is a magnetic contactor from the Deca sub-range, featuring an EverLink(TM) terminal design for screw connections. This 4-pole (4P; 4NO) contactor is rated for 80A (AC-1) and is designed for DIN rail mounting. It has a net width of 70 mm and offers a degree of protection of IP20. The control voltage for AC ranges from 480-660Vac (600Vac nominal; 50Hz; 0.8...1.1 x Uc) to 510-660Vac (600Vac nominal; 60Hz; 0.85...1.1 x Uc). It includes 1 Normally Open (NO) and 1 Normally Closed (NC) auxiliary contacts, with a contact type of 1NO+1NC instantaneous auxiliaries. The rated impulse voltage (Uimp) is 6 kV, and it has a mechanical durability of 6,000,000 operations at no load. The rated voltage (AC) phase-to-phase is 690 V.

Schneider Electric LC1DT80AR7 is a magnetic contactor from the Deca sub-range, featuring an EverLink(TM) terminal design and screw connections for secure installation. This 4-pole (4P; 4NO) contactor is designed to handle a rated current of 80A (AC-1) and can be mounted on a DIN rail. It has a net width of 70 mm and offers a degree of protection rated at IP20. The control voltage (AC) ranges from 352-484Vac (440Vac nominal; 50Hz; 0.8...1.1 x Uc) to 374-484Vac (440Vac nominal; 60Hz; 0.85...1.1 x Uc), with a rated operating voltage (Ue) of 690 V. It includes 1 Normally Open (NO) and 1 Normally Closed (NC) auxiliary contacts, with a contact type of 1NO+1NC instantaneous auxiliaries. The LC1DT80AR7 is designed for mechanical durability up to 6,000,000 operations at no load, has a rated impulse voltage (Uimp) of 6 kV, and supports a phase-to-phase rated voltage (AC) of 690 V.

Schneider Electric LC1DT80AFC7 is a magnetic contactor from the Deca sub-range, featuring EverLink(TM) terminals and screw connections. This 4-pole (4P; 4NO) contactor is designed for a rated current of 80A (AC-1) and can be mounted on a DIN rail. It has a net width of 70 mm and offers a degree of protection of IP20. The control voltage for AC ranges from 102-139Vac (127Vac nominal; 50Hz; 0.8...1.1 x Uc) to 108-139Vac (127Vac nominal; 60Hz; 0.85...1.1 x Uc). It includes 1 normally open (NO) and 1 normally closed (NC) auxiliary contacts, with a contact type of 1NO+1NC instantaneous auxiliaries. The mechanical durability of this contactor is rated at 6,000,000 operations at no load, and it can handle a rated impulse voltage (Uimp) of 6 kV. The rated voltage (AC) for phase-to-phase connections is up to 690 V.

Schneider Electric LC1D50A3T7 is a magnetic contactor from the Deca sub-range, featuring EverLink(TM) terminal design for connection. It is equipped with spring connections for control and screw connections for power, and it operates with 3 poles (3P; 3NO). This contactor is designed for a rated current of 80A under AC-1 conditions and 50A at 440Vac under AC-3 conditions. It supports DIN rail mounting and has a net width of 55 mm. The LC1D50A3T7 offers a degree of protection rated at IP20 and operates with a control voltage range of 384-528Vac at 50Hz and 408-528Vac at 60Hz, with a nominal control voltage of 480Vac. The rated operating voltage (Ue) is up to 690 V, and it includes 1 normally open (NO) auxiliary contact and 1 normally closed (NC) auxiliary contact, both of the instantaneous type (1NO+1NC). The rated impulse voltage (Uimp) is 6 kV. This contactor can handle rated active power ranging from 15kW at 220-230Vac to 33kW at 660-690Vac under AC-3 conditions. It also supports various rated power (HP) settings for different voltages and phases under UL/CSA standards, including 3HP at 115Vac and up to 40HP at 575-600Vac. The mechanical durability of the LC1D50A3T7 is rated at 6 million operations at no load, and its electrical durability is rated at 1.45 million operations with load. The rated voltage (AC) for phase-to-phase connections is 690 V.

Schneider Electric LC1D50A3S7 is a magnetic contactor from the Deca sub-range, featuring EverLink(TM) terminal design for connection. It is equipped with spring connections for control and screw connections for power, and it operates with 3 poles (3P; 3NO). The rated current is 80A for AC-1 and 50A for 440Vac in AC-3, with a mounting mode of DIN rail. The net width of the contactor is 55 mm, and it has an IP20 degree of protection. The control voltage (AC) ranges from 400-550Vac at 50Hz and 425-550Vac at 60Hz, with a nominal control voltage of 500Vac. The rated operating voltage (Ue) is up to 690 V, and it includes 1 normally open (NO) auxiliary contact and 1 normally closed (NC) auxiliary contact, both instantaneous. The rated impulse voltage (Uimp) is 6 kV. Rated active power spans from 15kW at 220-230Vac to 33kW at 660-690Vac in AC-3. Rated power in horsepower (HP) varies from 3HP at 115Vac to 40HP at 575-600Vac, under UL/CSA standards for both single-phase and 3-phase connections. The mechanical durability of the contactor is rated at 6,000,000 operations, and its electrical durability with load is 1,450,000 operations. The rated voltage (AC) phase-to-phase is 690 V.

Schneider Electric LC1D50A3Q7 is a magnetic contactor from the Deca sub-range, featuring EverLink(TM) terminal design for secure connections. It is equipped with spring connections for control and screw connections for power, and it operates with 3 poles (3P; 3NO). This contactor is designed for a rated current of 80A under AC-1 conditions and 50A at 440Vac under AC-3 conditions. It supports DIN rail mounting and has a net width of 55 mm. The LC1D50A3Q7 offers an IP20 degree of protection and operates with a control voltage (AC) range of 304-418Vac at 50Hz and 323-418Vac at 60Hz, with a nominal voltage of 380Vac. The rated operating voltage (Ue) is up to 690 V, and it includes 1 normally open (NO) auxiliary contact and 1 normally closed (NC) auxiliary contact, both of the instantaneous type (1NO+1NC). The rated impulse voltage (Uimp) is 6 kV. Its rated active power ranges from 15kW at 220-230Vac to 33kW at 660-690Vac under AC-3 conditions. The rated power in horsepower (HP) varies from 3HP at 115Vac in single-phase to 40HP at 575-600Vac in three-phase, according to UL/CSA standards. The mechanical durability of the LC1D50A3Q7 is rated at 6 million operations at no load, and its electrical durability is rated at 1.45 million operations with load. The rated voltage for phase-to-phase connections is 690 V.

Schneider Electric LC1D50A3N7 is a magnetic contactor from the Deca sub-range, featuring EverLink(TM) terminal design for secure connections. It is equipped with spring connections for control and screw connections for power, and operates with 3 poles (3P; 3NO). The contactor is rated for currents of 80A under AC-1 conditions and 50A at 440Vac under AC-3 conditions. It is designed for DIN rail mounting and has a net width of 55 mm. The LC1D50A3N7 offers an IP20 degree of protection and operates with a control voltage range of 332-456Vac at 50Hz and 353-456Vac at 60Hz, with a nominal control voltage of 415Vac. The rated operating voltage (Ue) is 690 V, and it includes 1 normally open (NO) auxiliary contact and 1 normally closed (NC) auxiliary contact, both of the instantaneous type (1NO+1NC). The rated impulse voltage (Uimp) is 6 kV. This contactor supports rated active power outputs ranging from 15kW at 220-230Vac to 33kW at 660-690Vac under AC-3 conditions. It also has rated power capacities for various horsepower ratings under UL/CSA standards, from 3HP at 115Vac to 40HP at 575-600Vac. The mechanical durability of the LC1D50A3N7 is rated at 6 million operations without load, and its electrical durability with load is 1.45 million operations. The rated voltage for phase-to-phase connections is 690 V.

Schneider Electric LC1D50A3F7 is a magnetic contactor from the Deca sub-range, featuring EverLink(TM) terminal design for secure connections. It is equipped with spring connections for control and screw connections for power, and it operates with 3 poles (3P; 3NO). The contactor is rated for currents of 80A under AC-1 conditions and 50A at 440Vac under AC-3 conditions. It is designed for DIN rail mounting and has a net width of 55 mm. The LC1D50A3F7 offers an IP20 degree of protection and operates with a control voltage of 88-121Vac at 50Hz and 93.5-121Vac at 60Hz. Its rated operating voltage (Ue) is up to 690 V, and it includes 1 normally open (NO) auxiliary contact and 1 normally closed (NC) auxiliary contact, both of the instantaneous type (1NO+1NC). The rated impulse voltage (Uimp) is 6 kV. This contactor can handle rated active power ranging from 15kW at 220-230Vac to 33kW at 660-690Vac under AC-3 conditions. It supports rated power in horsepower (HP) from 3HP at 115Vac in single-phase to 40HP at 575-600Vac in three-phase, according to UL/CSA standards. The mechanical durability of the LC1D50A3F7 is rated at 6 million operations without load, and its electrical durability with load is 1.45 million operations. The rated voltage for phase-to-phase connections is 690 V.

Schneider Electric LC1D506FW is a magnetic contactor from the Deca sub-range designed with a wide-range coil (0.75-1.2 x Uc) for flexibility in control voltage, which ranges from 82.5-132Vdc (110Vdc nominal). It features ring-lugs connections for secure wiring and is equipped with 3 poles (3P; 3NO) suitable for various applications. The contactor supports a rated current of 80A under AC-1 conditions and 50A at 440Vac under AC-3 conditions. It is designed for DIN rail mounting and offers an IP20 degree of protection. The rated operating voltage (Ue) is up to 690 V, and it includes 1 Normally Open (NO) auxiliary contact. The rated impulse voltage (Uimp) is 6 kV. Its rated active power capacity spans from 15kW at 220-230Vac to 33kW at 660-690Vac under AC-3 conditions. Additionally, it has 1 Normally Closed (NC) auxiliary contact with contacts type of 1NO+1NC instantaneous aux. The rated power in horsepower (HP) varies from 3HP at 115Vac to 40HP at 575-600Vac, accommodating a wide range of motor applications. The mechanical durability of the LC1D506FW is rated at 15 million operations at no load, and its phase-to-phase rated voltage (AC) reaches up to 690 V.

Schneider Electric LC1D40FD is a magnetic contactor from the Deca sub-range, featuring screw connections and designed with 3 poles (3P; 3NO). It has a rated current of 60A (AC-1) and 40A (440Vac; AC-3), with a mounting mode suitable for DIN rail installation. The degree of protection provided is IP20, and it operates with a control voltage (DC) range of 82.5-137.5Vdc (110Vdc nom.; 0.75...1.25 x Uc). The rated operating voltage (Ue) is up to 690 V, and it includes 1 normally open (NO) auxiliary contact. The rated impulse voltage (Uimp) is 6 kV. This contactor supports a rated active power of 11kW (220-230Vac; AC-3) up to 30kW (660-690Vac; AC-3), and it also features 1 normally closed (NC) auxiliary contact with contacts type of 1NO+1NC instantaneous aux. The rated power in horsepower (HP) ranges from 3HP at 115Vac to 30HP at 575-600Vac, suitable for various applications. It boasts a mechanical durability of 15 million operations at no load, and the rated voltage (AC) phase-to-phase is 690 V.
