RU600U-M30E-LI8X2-H1151 Turck Ultrasonic Sensors
Part#:RU600U-M30E-LI8X2-H1151
Manufacturer:Turck
Alt. Part#:1610100
Product Lifecycle:Active
Get a quick Quote!
RU600U-M30E-LI8X2-H1151 Ultrasonic Sensor, Diffuse Mode Sensor
About the manufacturer: Turck is one of the manufacturers that offers Ultrasonic Sensors that you can order at Powermatic Associates site. Turck is a leading provider of sensor, fieldbus, and connectivity technologies, along with interface technology, human-machine interfaces (HMI), and RFID systems. We offer innovative solutions for factory and process automation requirements, guaranteeing top-notch performance.
Check out the RU600U-M30E-LI8X2-H1151 Turck price in the box on the right side or send a quick quote.
Product Details
- Weight 320 g
- Ambient temperature -25…+50 °C
- Housing surface Nickel Plated
- Protection class IP67
- Housing quality CuZn
- Current output 4…20 mA
- Operating voltage 15…30 VDC
- Housing material Metal
- Design Threaded barrel
- Output function Analog output
- Electrical connection Connector, M12 × 1
- Range 600…6000 mm
- Construction size M30 x 1.5
- Function Proximity
- Radiation direction straight
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
RU600U-M30E-LI8X2-H1151 Description
Turck RU600U-M30E-LI8X2-H1151 is an ultrasonic sensor from the RU600U series, designed with a 15° sonic cone diffuse mode for front sensing. This sensor features ultrasonic sensor TEACH-by-wire functionality and is constructed with a chrome-plated brass housing and a sensing face made of PET (Polyethylene terephthalate), PU (Polyurethane), and Epoxy. It comes pre-equipped with a 5-pin M12 Eurofast QD male connector for connectivity. The sensor operates on a supply voltage of 15-30Vdc (24Vdc nom.) and can function within an ambient air temperature range of -25°C to +50°C. It offers a degree of protection of IP67 and has a partially threaded extended cylindrical/barrel shape with an M30 thread size. The RU600U-M30E-LI8X2-H1151 features 1 digital output (15-30Vdc; PNP; fixed threshold; 150mA max.) and 1 analog output (4-20mA), with a sensing distance of 600-6000mm. Its current consumption is 50mA (no-load current), and it has a maximum switching frequency of 1.6Hz. The sensor provides protection functions against short-circuit (pulsed) and reverse polarity, operates with a transmission frequency of 75kHz / 0.075 MHz, and offers a measurement accuracy (resolution) of 1mm, with a control circuit rated current of 50mA / 0.05 A.
Related documents RU600U-M30E-LI8X2-H1151 Specs
