RM-106C14E1-9N32B-B3M12 Turck Encoders

Name: RM-106C14E1-9N32B-B3M12
Brand: Turck

Turck RM-106C14E1-9N32B-B3M12 RM-106C14E1-9N32B-B3M12 Absolute Hollow Shaft Encoder, Industrial Line

Part#:RM-106C14E1-9N32B-B3M12

Manufacturer:Turck

Alt. Part#:1545679

Product Lifecycle:Active

Get a quick Quote!

RM-106C14E1-9N32B-B3M12 Absolute Hollow Shaft Encoder, Industrial Line

About the manufacturer: Turck is one of the manufacturers that offers Encoders that you can order at Powermatic Associates site. Turck is a leading provider of sensor, fieldbus, and connectivity technologies, along with interface technology, human-machine interfaces (HMI), and RFID systems. We offer innovative solutions for factory and process automation requirements, guaranteeing top-notch performance.

Check out the RM-106C14E1-9N32B-B3M12 Turck price in the box on the right side or send a quick quote.

Product Details

Encoder line
Industrial-Line
Protection class
IP65
Protection class shaft
IP65
Housing material
Die-cast zinc
Operating voltage
10…30 VDC
Shaft Type
Hollow shaft
Output type
Absolute multiturn
Ambient temperature
-40…+80 °C
Technology
Optical
Communication protocol
EtherNet/IP
Flange diameter
Ø 65 mm

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

RM-106C14E1-9N32B-B3M12 Description

Turck RM-106C14E1-9N32B-B3M12 is an absolute multi-turn encoder within the Type RM-106 series, featuring a through hollow shaft flange with flex mount optical sensing. It is constructed with a die-cast Zinc housing, a Stainless steel shaft, an Aluminium flange, and a PVC cable. This encoder is pre-equipped with axial M12 Eurofast QD connectors x 3 for connectivity. It has dimensions of H90mm x W70mm x D80mm with a 58mm casing diameter and operates on a supply voltage of 10Vdc-30Vdc (12Vdc-24Vdc nom.). The mounting mode is a 65mm flex mount flange mounting. It is designed to operate in ambient air temperatures ranging from -40 to +80��C and offers a degree of protection of IP65. The bore size is a 14mm hollow shaft bore, and it utilizes the DeviceNet communication protocol.

Manufacturer warranty
