REM-E-121T10S-9F32B-H1151 Turck Industrial Automation Components
Part#:REM-E-121T10S-9F32B-H1151
Manufacturer:Turck
Category:Industrial Automation Components
Alt. Part#:100023366
Product Lifecycle:Active
Get a quick Quote!
REM-E-121T10S-9F32B-H1151 Turck - REM-E-121T10S-9F32B-H1151 Absolute Rotary Encoder - Multiturn, Efficiency Line
About the manufacturer: Turck is one of the manufacturers that offers Industrial Automation Components that you can order at Powermatic Associates site. Turck is a leading provider of sensor, fieldbus, and connectivity technologies, along with interface technology, human-machine interfaces (HMI), and RFID systems. We offer innovative solutions for factory and process automation requirements, guaranteeing top-notch performance.
Check out the REM-E-121T10S-9F32B-H1151 Turck price in the box on the right side or send a quick quote.
Product Details
- Weight 374 g
- Country Of Origin DEU
- HTS Code 9032894000
- Weight 374 grams
- Operating Voltage 10 volts, 30 volts
- Ambient Temperature -20 degrees celsius, 70 degrees celsius
- Country of Origin Germany
- Protection class shaft IP64
- Protection class IP64
- Ambient temperature -20…+70 °C
- Housing material Die-cast zinc
- Technology Magnetic
- Electrical connection Connector, M12 × 1
- Encoder line Efficiency-Line
- Communication protocol SAE J1939
- Operating voltage 10…30 VDC
- Flange type Synchro flange
- Flange diameter Ø 58 mm
- Output type Absolute multiturn
- Shaft diameter D [mm] 10 mm
- Shaft Type Solid shaft
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
REM-E-121T10S-9F32B-H1151 Description
Absolute Rotary Encoder - Multiturn, Efficiency Line, Ø 58 mm servo flange, Solid shaft, Ø 10mm x 20mm, Optical measuring principle, Shaft material, stainless steel, , Protection class IP64 on housing and shaft side, ‐20…+70 °C, Max. 4000 rpm (continuous operation 2000 rpm), Energy harvesting technology, 10-30 VDC, SAE J1939, M12 connection, 5-pin, Singleturn resolution 14 bit scalable, default 14 bit, Multiturn resolution scalable up to 29 bit over total resolution, default 18 bit, Total resolution 32 bit scalable, default: 32 bit
Related documents REM-E-121T10S-9F32B-H1151 Specs
