ATV61HD18N4S337 Schneider Electric Variable Frequency Drives (VFD)

Schneider Electric

Part#:ATV61HD18N4S337

Manufacturer:Schneider Electric

Product Lifecycle:Active

Get a quick Quote!

Schneider Electric ATV61HD18N4S337 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the Altivar 61 series designed for variable speed and frequency control with U/F ratio adjustment options (2 points / 5 points / energy saving), sensorless flux vector control (standard / energy saving), and vector control without speed feedback capable of delivering 120% of the nominal motor torque. It features a built-in DC choke, an EMC filter (class C2), a built-in heatsink, and a coated version for enhanced durability. The supply voltage ranges from 323-528Vac, supporting 380Vac, 400Vac, 480Vac, and 500Vac nominal values. Its dimensions are H400mm x W230mm x D213mm, and it has a conformal coating for chemical resistance, classified as a reinforced version. The degree of protection is IP20 UL type 1. The rated current is 41A at 380Vac (12kHz), 34A at 460Vac (12kHz), with a maximum current of 49.2A for 60 seconds. It is designed for wall mounting and supports Modbus and CANopen communication protocols. This 3-phase (3P) network device outputs frequencies from 0.1 to 599 Hz. It includes 1 analog output (0-10Vdc / 0-20mA), 5 digital inputs (24Vdc; sink/source) plus 1 additional digital input programmable as discrete or PTC input, and 1 PWR safety input. There are also 2 digital outputs (1 C/O SPDT relay contact and 1 NO relay contact), along with 2 analog inputs (-10...+10Vdc and 0-10Vdc / 0-20mA). The current consumption is 45.5A at 380Vac and 37.5A at 480Vac, with a rated active power of 18.5kW and a rated power of 25HP.

About the manufacturer: Schneider Electric is one of the manufacturers that offers Variable Frequency Drives (VFD) that you can order at Powermatic Associates site. We provide digital solutions for energy and automation that improve efficiency and support sustainability. Our comprehensive solutions include cutting-edge energy technologies, real-time automation, software, and services for residential, commercial, and industrial settings.

Check out the ATV61HD18N4S337 Schneider Electric price in the box on the right side or send a quick quote.

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

ATV61HD18N4S337 Description

Schneider Electric ATV61HD18N4S337 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the Altivar 61 series designed for variable speed and frequency control with U/F ratio adjustment options (2 points / 5 points / energy saving), sensorless flux vector control (standard / energy saving), and vector control without speed feedback capable of delivering 120% of the nominal motor torque. It features a built-in DC choke, an EMC filter (class C2), a built-in heatsink, and a coated version for enhanced durability. The supply voltage ranges from 323-528Vac, supporting 380Vac, 400Vac, 480Vac, and 500Vac nominal values. Its dimensions are H400mm x W230mm x D213mm, and it has a conformal coating for chemical resistance, classified as a reinforced version. The degree of protection is IP20 UL type 1. The rated current is 41A at 380Vac (12kHz), 34A at 460Vac (12kHz), with a maximum current of 49.2A for 60 seconds. It is designed for wall mounting and supports Modbus and CANopen communication protocols. This 3-phase (3P) network device outputs frequencies from 0.1 to 599 Hz. It includes 1 analog output (0-10Vdc / 0-20mA), 5 digital inputs (24Vdc; sink/source) plus 1 additional digital input programmable as discrete or PTC input, and 1 PWR safety input. There are also 2 digital outputs (1 C/O SPDT relay contact and 1 NO relay contact), along with 2 analog inputs (-10...+10Vdc and 0-10Vdc / 0-20mA). The current consumption is 45.5A at 380Vac and 37.5A at 480Vac, with a rated active power of 18.5kW and a rated power of 25HP.

Manufacturer warranty

Get a quick Quote!

Request a quote, and we will send you price and availability within minutes.

Select Qty:

Average response time: 11 minutes

Worldwide Shipping and Delivery

Secure Payment Processing

Warranty

Responsive Customer Support
