7961612 SAB Torsional Cables

7961612 on Powermatic Associates
SAB

Part#:7961612

Manufacturer:SAB

Product Lifecycle:Active

Get a quick Quote!

RT 123 D - 16 AWG/12c, Spiral shielded PUR rugged and dependable robot/track cable, �450� torsion

About the manufacturer: SAB is one of the manufacturers that offers Torsional Cables that you can order at Powermatic Associates site. SAB North America acts as the central hub for sales, distribution, and service for SAB Bröckskes, a German company that specializes in cables, wires, cable harnesses, and temperature measurement tools. Our top-quality cables are shipped to more than 40 countries on a daily basis.

Check out the 7961612 SAB price in the box on the right side or send a quick quote.

Product Details

  • Color
    Black
  • Weight
    102.97 g
  • Chemical Resistant
    YES
  • Oil Resistant
    Yes
  • UV Resistant
    YES
  • Halogen Free
    YES
  • Submersible
    NO
  • Direct Burial
    NO
  • Movement Type
    Torsional
  • Application
    Control, Data
  • Gauge
    16 AWG
  • Number of conductors
    12
  • Cable configuration
    16 AWG (≈ 84/34)/12c
  • Stranding type
    bare copper strands, class 6
  • Insulation type
    TPE
  • Shielded
    Yes
  • Voltage
    600
  • Approvals
    UR AWM, CSA AWM, CE, EAC, RoHS
  • RoHS
    YES
  • Temperature range
    -50°C to +90°C
  • Outside diameter (OD)
    0.587 in
  • UOM
    ft
  • CSA Certification
    YES
  • UL Certification
    YES
  • CE Certification
    YES

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

7961612 Description

SAB 7961612 Torsional Cable is part of RT 123 D product family, and is designed for Control, Data applications. This cable is 16 AWG with 12 conductors, and shielded 16 AWG (≈ 84/34)/12c cable configuration. Featuring Black color jacket, TPE insulation, and bare copper strands, class 6 stranding. It has 0.587 in OD, constructed to support Torsional movement type, and rated for 600 volts. This Control, Data cable can operate in -50°C to +90°C temperature range, it is chemical resistant, oil resistant, UV resistand, Halogen free, and has following approvals: UR AWM, CSA AWM, CE, EAC, RoHS. This cable is an excellent choice for Control, Data applications.

Related documents 7961612 Specs

7961612 RT_123_D.pdf

Manufacturer warranty

Get a quick Quote!

Request a quote, and we will send you price and availability within minutes.
