7742510 SAB Multiconductor Cables

7742510 on Powermatic Associates
SAB

Part#:7742510

Manufacturer:SAB

Product Lifecycle:Active

Get a quick Quote!

S 200 - 18 AWG/25c, halogen free continuous flex oil resistant data & control cable, CE, RoHS

About the manufacturer: SAB is one of the manufacturers that offers Multiconductor Cables that you can order at Powermatic Associates site. SAB North America acts as the central hub for sales, distribution, and service for SAB Bröckskes, a German company that specializes in cables, wires, cable harnesses, and temperature measurement tools. Our top-quality cables are shipped to more than 40 countries on a daily basis.

Check out the 7742510 SAB price in the box on the right side or send a quick quote.

Product Details

  • Color
    Gray
  • Weight
    107.50 g
  • Chemical Resistant
    YES
  • Oil Resistant
    Yes
  • UV Resistant
    NO
  • Halogen Free
    YES
  • Submersible
    NO
  • Direct Burial
    NO
  • Movement Type
    Continuous Flex
  • Application
    Control, Power
  • Gauge
    18 AWG
  • Number of conductors
    25
  • Cable configuration
    18 AWG (≈ 56/34)/25c
  • Stranding type
    bare copper strands, class 6
  • Insulation type
    TPE
  • Shielded
    No
  • Voltage
    500
  • Approvals
    CE, EAC, RoHS
  • RoHS
    YES
  • Temperature range
    -50°C to +90°C
  • Outside diameter (OD)
    0.594 in
  • UOM
    ft
  • CSA Certification
    NO
  • UL Certification
    NO
  • CE Certification
    YES

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

7742510 Description

SAB 7742510 Continuous Flex Cable is part of S 200 product family, and is designed for Control, Power applications. This cable is 18 AWG with 25 conductors, and 18 AWG (≈ 56/34)/25c cable configuration. Featuring Gray color jacket, TPE insulation, and bare copper strands, class 6 stranding. It has 0.594 in OD, constructed to support Continuous Flex movement type, and rated for 500 volts. This Control, Power cable can operate in -50°C to +90°C temperature range, it is chemical resistant, oil resistant, Halogen free, and has following approvals: CE, EAC, RoHS. This cable is an excellent choice for Control, Power applications.

Related documents 7742510 Specs

7742510 S_200.pdf
