170917 Festo Pneumatic Actuators

Product Details

• Max. static moment Mx
  14.79 Nm
• Max. static moment Mz
  5.61 Nm
• Max. force Fy
  408 N
• Stroke
  30 mm
• Symbol
  00991737
• Information on operating and pilot media
  Operation with oil lubrication possible (required for further use)
• Max. payload as a function of the stroke at defined distance xs
  42 N
• Note on materials
  Free of copper and PTFE RoHS-compliant
• Piston rod material
  High-alloy stainless steel
• Distance of centre of gravity of payload to yoke plate xs
  50 mm
• Center of gravity of the moving mass as a function of the stroke
  20.8 mm
• Piston diameter
  20 mm
• Cushioning
  Elastic cushioning rings/pads at both ends
• Position sensing
  For proximity sensor
• Mode of operation
  Double-acting
• Ambient temperature
  -5 °C ... 60 °C
• Product weight
  822 g
• Alternative connections
  See product drawing
• Seals material
  NBR
• Max. torque My
  4.49 Nm
Max. torque Mz
4.49 Nm
Design
Guide
Corrosion resistance class (CRC)
0 - No corrosion stress
Theoretical force at 6 bar, advancing
188 N
Cover material
Wrought aluminum alloy
Max. permissible torque load Mx as a function of the stroke
2.08 Nm
Max. force Fz static
510 N
Type code
DFM
Guide
Recirculating ball bearing guide
Operating pressure
0.2 MPa ... 1 MPa
Operating medium
Compressed air as per ISO 8573-1:2010 [7:4:4]
Moving mass
400 g
Pneumatic connection
M5
Housing material
Wrought aluminum alloy
Max. static moment My
5.61 Nm
Max. force Fy static
510 N
Max. force Fz
408 N
Drive unit operating mode
Yoke
Mounting position
Any
Max. speed
0.8 m/s
Max. torque Mx
11.84 Nm
Impact energy in the end positions
0.2 J
Theoretical force at 6 bar, retracting
141 N
