FAZ-B32/4 Eaton Miniature Circuit Breakers (MCBs)
Part#:FAZ-B32/4
Manufacturer:Eaton
Product Lifecycle:Active
Get a quick Quote!
UL 1077 Industrial Miniature Circuit Breaker - Supplementary Protector
About the manufacturer: Eaton is one of the manufacturers that offers Miniature Circuit Breakers (MCBs) that you can order at Powermatic Associates site. At Eaton, we are dedicated to improving quality of life and preserving the environment through power management technologies that emphasize reliability, efficiency, safety, and sustainability. Our attention is on impactful solutions, and we are committed to their success.
Check out the FAZ-B32/4 Eaton price in the box on the right side or send a quick quote.
Product Details
- Terminal Type Compression
- Trip Curve B
- UL CCN QVNU2
- UL File No. E177451
- Number of Poles 4 Pole
- Current Rating 32 A
- SCCR 10 kA
- UL Standard 1077
- Number of poles Four-pole
- Circuit protection B curve
- Trip Type 3-5X /n
- Application Suitable for applications where low levels of inrush current are expected
- Amperage Rating 32 A
- Type UL 1077 Industrial miniature circuit breaker - supplementary protector
- Catalog Notes For applications that require protection due to potential wiring damage at low fault conditions.
- Terminals Standard
- Interrupt rating 15 kAIC
- Frequency rating 50-60 Hz
- Product Height 2.76 in
- Certifications IEC 60947-2 CSA Std. C22.2 No.235 UL 1077
- Product Width 2.9 in
- Warranty 1 year
- Product Weight .5 lb
- Product Length/Depth 2.76 in
- Catalog Number FAZ-B32/4
- EAN 4015082790387
- Product Name Eaton FAZ supplementary protector
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
Related documents FAZ-B32/4 Specs
