SX5-M70 Banner Safety Light Curtains

SX5-M70 on Powermatic Associates
Banner

Part#:SX5-M70

Manufacturer:Banner

Category:Safety Light Curtains

Alt. Part#:807768

Product Lifecycle:Active

Get a quick Quote!

SX5 Series Safety Laser Scanner, Master; Safety Zone Sets: 70; Safety Outputs: 3 OSSD Pairs; Removable Memory: 17-pin and 8-pin; Protective Field Range: 0.05 m to 5.5 m; Scanning Angle Degrees (max): 275

About the manufacturer: Banner is one of the manufacturers that offers Safety Light Curtains that you can order at Powermatic Associates site. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.

Check out the SX5-M70 Banner price in the box on the right side or send a quick quote.

Product Details

  • Weight
    2204.45712 g
  • Country Of Origin
    IT
  • Replaceable Window
    Yes
  • Operating Voltage
    24 V dc +/- 20%
  • Safe Outputs
    6
  • Laser Classification
    Class 1
  • Power Consumption
    0.3 A (exclusive of load)
  • Safe Output Rating
    OSSD 0.250 A max. @ 24 V dc
  • Encoder Inputs
    No
  • Scanner Type
    Master
  • Removable Memory
    Yes
  • Available Resolutions (mm)
    30, 40, 50, 70, 150

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

SX5-M70 Description

Banner Engineering SX5-M70 is a safety laser scanner designed as a master model. It features a Safety class 1 Laser scanner protective field and is pre-equipped with an 8-pin Euro-style M12 connector for connections. This part operates on a 24Vdc supply voltage and can function within an ambient air temperature range of 0 to +50°C. It is rated with a degree of protection of IP65, ensuring its suitability for various industrial environments. The SX5-M70 is equipped with 1 x digital output, which includes 3 x OSSD outputs, and offers a sensing distance ranging from 5cm to 5.5m.

Related documents SX5-M70 Specs

SX5-M70 208913.pdf
