P32-C6 Banner Through Beam Sensors

P32-C6 on Powermatic Associates
Banner

Part#:P32-C6

Manufacturer:Banner

Alt. Part#:12789

Product Lifecycle:Active

Get a quick Quote!

Plastic Fiber, Convergent Distance 6 mm; Side Exit; Flat Pack Plastic Housing; 2 m Fiber Length; Free Cut

About the manufacturer: Banner is one of the manufacturers that offers Through Beam Sensors that you can order at Powermatic Associates site. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.

Check out the P32-C6 Banner price in the box on the right side or send a quick quote.

Product Details

  • Weight
    30.844256 g
  • Country Of Origin
    TW
  • Measured Max Distance (mm)
    No Data
  • Tariff Fiber Meters (fbm)
    4
  • Max Distance: DF-G2 (mm)
    No Data
  • Max Distance: DF-G1 (mm)
    No Data
  • Max Distance: DF-G3 (mm)
    No Data
  • Application: Vacuum Feed Through
    None
  • Termination Type
    Plastic Fiber Sensors
  • Application: Liquid Level
    No
  • Integrated Lens
    No
  • Feature: Small Object Detection
    No
  • Feature: Chemical Resistant
    No
  • Feature: Extended Range
    No
  • Minimum Repeat Bending Endurance
    1000
  • Max Temp ( °C)
    70
  • Termination
    Free Cut
  • Minimum Bend Radius (mm)
    19
  • Retractile
    No
  • Core Diameter (mm)
    0.5
  • Flex Relief
    No
  • Sensing End Segment 2
    Sideview
  • Fiber Sensing End Size
    13.0 x 19.7 mm
  • Sensing End Segment 1
    Rectangle
  • Sensing End Material (Specific)
    Polyethylene
  • Fiber Optic Type
    Plastic
  • Fiber Sheathing Material (Jacket)
    Polyethylene
  • Fiber Sensing End Tip
    Sideview
  • Sensing Mode (General)
    Diffuse
  • Housing Style
    Rectangular
  • Fiber Sensing End Size - Mounting Area
    13.0 x 19.7 mm
  • Fiber Length (m)
    2
  • Beam Exit
    Right Angle
  • Quantity Included
    1
  • Sensing Mode (Detailed)
    Convergent
  • Main function
    Fiber sensor
  • Length
    6ft / 2m
  • Material
    Plastic sensing end Plastic fiber Polyethylene fiber sheath
  • Primary brand
    Banner Engineering
  • Diameter
    0.5mm fiber core
  • Ambient air temperature for operation
    +70 °C
  • Sub-range name
    Plastic fiber series
  • Equivalent to
    P32C6
  • Product series / family name
    Fiber sensors
  • Shape
    Rectangular
  • Order code / Manufacturer SKU
    12789
  • Design
    diffuse-reflective system
  • Functions
    Fiber optic sensor
  • Dimensions
    19.7x13mm sensing area

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

P32-C6 Description

Turck P32-C6 is a mounting accessory designed as a positioning element.

Related documents P32-C6 Specs

P32-C6 P32-C6-1630955042114.pdf
P32-C6 P32-C6-1630955042116.stp

Manufacturer warranty

$186.00
