Schneider Electric Industrial Automation Components on Powermatic Associates

Square D by Schneider Electric NQ430L4C is a panelboard designed for three-phase (3PH-4W) networks, featuring a copper busbar and rated for a current of 400A. It accommodates a voltage of 240Vac and 48Vdc, suitable for a variety of applications. The dimensions of this panelboard are H50" x W20", providing 30 spaces for circuits. It supports a cross-section range from 1/0AWG to 750kcmil for both line and neutral aluminium lugs, allowing for flexible installation options. This panelboard is specifically crafted to house 30 circuits, ensuring ample capacity for electrical distribution needs.

Square D by Schneider Electric LGL36600U53XENAAUOYH1 is a Moulded Case Circuit Breaker (MCCB) within the PowerPacT LGL sub-range. It features a factory-installed 24Vdc undervoltage (U/V) trip release coil and a factory-installed 1A/1B (1NO+1NC) auxiliary switch OF wire harness. Designed for PowerPacT L-Frame, this 3-pole (3P) breaker has a rated current of 600A and operates at a rated voltage of 600Vac and 600Y/347Vac, with a rated insulation voltage (Ui) of 750V. It offers long-time (L), short-time with fixed time delay (S), instantaneous (I), and Zone Selective Interlocking (ZSI) protection functions. The breaker is equipped with lugs on both load and line sides for connection and is designed for individual unit mount on plate. It has a net height of 382mm, width of 153mm, depth of 171mm, and offers a degree of protection of IP40. The operating mode is manual toggle, with protection settings adjustable for overload, short-circuit with time delay, and instantaneous protection against short-circuit. The control voltage for the undervoltage trip coil allows circuit breaker opening at 35% to 70% of its rated control voltage, with closing permitted when the supply voltage reaches 85% of rated control voltage. The rated operating voltage (Ue) is 690V, with a rated impulse voltage (Uimp) of 8kV. The trip current rating is 600 AT, with a frame current rating of 600 AF. It has a short circuit breaking rating of up to 65kA at 240Vac under UL489 standards. The trip unit type is an electronic Micrologic Energy 5.3E (LSI) with an LCD display, offering comprehensive measurement functions for current, voltage, power, energy metering, power quality, and harmonic analysis. The utilisation category is A.

Schneider Electric - 9080LB23

Schneider Electric - AB1RV

Schneider Electric RSZR215, part of the RSB sub-range, is a marking accessory designed for use as a plastic maintaining clamp.

Schneider Electric RXM021RB is a suppressor module within the RXG sub-range, featuring a varistor function. It is designed to operate with a rated voltage of 6-24 V for both DC and AC phase-to-neutral applications.

Schneider Electric LC1F225M6 is a high-power magnetic contactor within the F sub-range, designed for surface mounting. It features a 3-pole (3P; 3NO) configuration and supports ring-lugs/bar connections. The contactor is rated for currents of 315A under AC-1 conditions and 225A at 440Vac under AC-3 conditions. It operates with a control voltage (AC) range of 187-242Vac (220Vac nominal; 60Hz; 0.85...1.1 x Uc) and has a rated operating voltage (Ue) of up to 1000 V. This model comes without normally open (NO) or normally closed (NC) auxiliary contacts. It is capable of handling rated impulse voltage (Uimp) of 8 kV and supports rated active power (kW) of 63kW at 220-230Vac, 110kW at 380-400Vac, 415Vac, and 440Vac, 129kW at 500Vac and 660-690Vac, and 100kW at 1000Vac, all under AC-3 conditions. The LC1F225M6 boasts a mechanical durability of 10 million operations at no load and is designed for phase-to-phase rated voltage (AC) applications up to 1000 V.

Schneider Electric RPM11BD is a power plug-in relay within the RPM sub-range, designed for versatile switching applications. This relay features contacts made from an Ag/Ni - Silver-Nickel alloy, ensuring durability and conductivity. It operates with a single pole double throw (SPDT) contact type, suitable for a variety of circuit configurations. The control voltage for this device is specified at 24 Vdc, with a rated current of 15 A for both 250Vac (AC-1) and 28Vdc (DC-1) applications. It is designed for plug-in mounting, allowing for easy installation and maintenance. The RPM11BD can operate within an ambient air temperature range of -40 to +55 ��C and comes with an IP40 degree of protection, indicating a basic level of protection against solid objects.

SUPERPROX ULTRASONIC PROXIMITY SENSOR

Schneider Electric ZB5AV053 is a head for integral LED within the XB5 sub-range, featuring a plastic body and bezel. This component is round in shape, with a diameter of 22 mm, and comes equipped with a plain lens. It is designed to emit an orange light. The ZB5AV053 offers a degree of protection rated at IP66, IP67, NEMA 4X, and NEMA 13, indicating its capability to withstand dust, water, and other environmental conditions.
