FCI-D10A4P-2ARX-H1160/D205 Turck Flow Sensors

Turck FCI-D10A4P-2ARX-H1160/D205 FCI-D10A4P-2ARX-H1160/D205 Flow Monitoring, Inline Sensor with Integrated Processor, Relay Output 24 VDC NO
Turck

Part#:FCI-D10A4P-2ARX-H1160/D205

Manufacturer:Turck

Alt. Part#:6870681

Product Lifecycle:Active

Get a quick Quote!

FCI-D10A4P-2ARX-H1160/D205 Flow Monitoring, Inline Sensor with Integrated Processor, Relay Output 24 VDC NO

About the manufacturer: Turck is one of the manufacturers that offers Flow Sensors that you can order at Powermatic Associates site. Turck is a leading provider of sensor, fieldbus, and connectivity technologies, along with interface technology, human-machine interfaces (HMI), and RFID systems. We offer innovative solutions for factory and process automation requirements, guaranteeing top-notch performance.

Check out the FCI-D10A4P-2ARX-H1160/D205 Turck price in the box on the right side or send a quick quote.

Product Details

  • Weight
    628 g
  • Ambient temperature
    -20…+60 °C
  • Medium temperature
    -10…+95 °C
  • Protection class
    IP65
  • Housing material
    Plastic, POM
  • Sensor material
    Stainless steel
  • Electrical connection
    Connector, M12 × 1
  • Function
    Flow rate measurement
  • Operating voltage
    21.6…26.4 VDC
  • Operating principle
    Calorimetric
  • Output function
    NO contact, Relay output
  • Process connection
    1/2” Swagelok
  • Design
    Inline
  • Medium
    liquids

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

FCI-D10A4P-2ARX-H1160/D205 Description

Turck FCI-D10A4P-2ARX-H1160/D205 is a sensor designed for flow monitoring with a PBT (Polybutylene Terephthalate) housing, Stainless steel 316Ti tubing, and Stainless steel 303 connector. It operates within an ambient air temperature range of -20°C to +60°C and offers a degree of protection rated at IP65. The sensor has a response time of 2-15 seconds during startup and 500ms to 3 seconds in normal operation, featuring 2 digital outputs (NO Normally Open relay dry contacts). Its rectangular body is designed for dual setpoint functionality and is pre-equipped with a 5-pin M12 Eurofast QD male connector and 1/2" Swagelok threaded process ports. The control circuit rated current is 0.5 A at 30Vdc and 1 A at 36Vdc, capable of monitoring flow rates from 0.2 to 5 gallons per minute (GPM) for water. This sensor is part of the FCI series, designed to function as an instrumentation inline flow monitor sensor/switch, capable of handling pressures up to 20bar (290psi). It requires a supply voltage of 21.6-26.4Vdc (24Vdc nominal) and can monitor medium temperatures ranging from -10°C to +70°C.

Related documents FCI-D10A4P-2ARX-H1160/D205 Specs

FCI-D10A4P-2ARX-H1160/D205 English.pdf
