Name: CONDUIT ADAPTOR PLATE 3/4 IN FORM 7
Brand: Turck

GVAN11

Schneider Electric GVAN11 is an auxiliary contact designed for use with the GV3 range, providing breaker status indication (Open/Closed). It features a rated insulation voltage (Ui) of 690 V, equipped with 1 Normally Open (NO) and 1 Normally Closed (NC) auxiliary contacts. The GVAN11 is engineered for mechanical durability of up to 100,000 operations at no load and maintains the same level of electrical durability with load, ensuring a total of 100,000 operations.

Schneider Electric

53

RSC RKC 572-2M

Cable for DeviceNet and CANopen, Extension Cable, Cable length (L) 2 m, M12 female connector, straight, A-coded, M12 male connector, straight, A-coded, M12, Male, Straight, 5-pin, A-Code, M12, Female, Straight, 5-pin, A-Code, Shielded Twisted Pair, Fieldbus Technology Cable, fieldbus type: DeviceNet™, Gray PVC jacket, shielded, 2STPX22 AWG, Sunlight Resistant, Flame Ratings: UL 1685 FT4, UL1061, CSA FT4, Cable length: 2 m

Turck

46

PKG 3M-3.5-PSG 3

Turck PKG 3M-3.5-PSG 3 is a double-ended cable/cordset designed for automation applications, featuring a 4.4mm cable sheath outer diameter and a length of 3.5 meters (approximately 11 feet). It is equipped with a 3-pin M8 picofast female connector and a 3-pin M8 picofast male connector, both with M8x1 threaded coupling nuts, facilitating secure connections. This cable operates with a rated current of 4A and a rated voltage of 125Vac. It is constructed with a PVC jacket and nickel-plated brass coupling nuts, ensuring durability. The cable supports a 3-wire configuration with a cross-section of 3 x #24AWG. It offers a high degree of protection, rated at IP67, NEMA 1, NEMA 3, NEMA 4, and NEMA 6P, suitable for various environmental conditions. The cable sheath is colored yellow for easy identification.

Turck

22

AS3-CCDC-FF

AC Current Switch, Solid Core, Adjustable Setpoint, 1-6, 6-40 & 40-175 Amp Ranges, Front Terminals, w/o LED, 1 N.O, 1 N.C., 0.15 A @ 30 VDC

NK Technologies

2

RXM4AB2BD

Schneider Electric RXM4AB2BD is a miniature plug-in relay within the RXM sub-range, featuring contacts made from an Ag/Ni - Silver - Nickel alloy. This relay is designed with 4C/O - 4PDT (4 Pole Double Throw) contact type, and operates with a control voltage of 24 Vdc. It is rated for a current of 6 A at both 250Vac (AC-1) and 28Vac (DC-1). The RXM4AB2BD offers plug-in mounting mode and can operate within an ambient air temperature range of -40 to +55 °C. It has an IP40 degree of protection and a current consumption of 0.038 A. This model includes a visual position indicator through an LED, consumes 0.9 W of power, and boasts an electrical durability of 100,000 operations with a resistive load, alongside a mechanical durability of 10,000,000 operations at no load. Additionally, it features a Lockable Test Button (LTB) for latching.

Schneider Electric

53

QOB210

Square D by Schneider Electric QOB210 is a Miniature Circuit Breaker (MCB) designed for bolt-on mounting. It features a rated current of 10A and accommodates a bolt-on connection type. This MCB is compatible with a voltage rating of 48Vdc and 120V/240V AC, supporting a cross-section of 14-8AWG for 1 cable Al/Cu. It is a 2 Pole device with a short circuit breaking rating of 10kA at 240Vac and 5kA at 48Vdc. The terminals are of the press plate type.

Schneider Electric

5

B 4151-0/9

Actuator and Sensor Field Wireable, 7/8 Connection, Voltage 600 V, 7/8” Female, Straight, 5-pin, Plastic Housing, Screw terminal Wire Termination, "

Turck

2
