62000310 SAB Halogen Free Cables

SAB 62000310 SABIX A 200 FRNC - 16 AWG/3c, low smoke halogen free flame retardant flexible SABIX control cable, CE, RoHS
SAB

Part#:62000310

Manufacturer:SAB

Product Lifecycle:Active

Get a quick Quote!

SABIX A 200 FRNC - 16 AWG/3c, low smoke halogen free flame retardant flexible SABIX control cable, CE, RoHS

About the manufacturer: SAB is one of the manufacturers that offers Halogen Free Cables that you can order at Powermatic Associates site. SAB North America acts as the central hub for sales, distribution, and service for SAB Bröckskes, a German company that specializes in cables, wires, cable harnesses, and temperature measurement tools. Our top-quality cables are shipped to more than 40 countries on a daily basis.

Check out the 62000310 SAB price in the box on the right side or send a quick quote.

Product Details

  • Weight
    20.41 g
  • Cable configuration
    18 AWG (≈ 30/32)/3c
  • UL Certification
    NO
  • Oil Resistant
    No
  • Direct Burial
    NO
  • Voltage
    500
  • Insulation type
    SABIX
  • CE Certification
    YES
  • Halogen Free
    YES
  • Submersible
    NO
  • Approvals
    CE, EAC, RoHS
  • UV Resistant
    YES
  • Application
    Control, Power
  • RoHS
    YES
  • Gauge
    18 AWG
  • Number of conductors
    3
  • UOM
    ft
  • Chemical Resistant
    NO
  • Movement Type
    Stationary/Flexible
  • Temperature range
    -40°C to +85°C
  • Outside diameter (OD)
    0.248 in
  • Stranding type
    bare copper strands, class 5
  • CSA Certification
    NO
  • Shielded
    No
  • Color
    Gray

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

62000310 Description

SAB 62000310 Halogen Free Cable is part of SABIX® A 200 FRNC product family, and is designed for Control, Power applications. This cable is 18 AWG with 3 conductors, and 18 AWG (≈ 30/32)/3c cable configuration. Featuring Gray color jacket, SABIX insulation, and bare copper strands, class 5 stranding. It has 0.248 in OD, constructed to support Stationary/Flexible movement type, and rated for 500 volts. This Control, Power cable can operate in -40°C to +85°C temperature range, it is UV resistand, Halogen free, and has following approvals: CE, EAC, RoHS. This cable is an excellent choice for Control, Power applications.

Related documents 62000310 Specs

62000310 SABIX_A_200_FRNC.pdf
