K50BLXRXPQ
Banner
Product Lifecycle: Active
Banner Engineering K50BLXRXPQ is a high-intensity industrial LED light beacon from the EZ-LIGHT Beacons series, designed for perimeter view indication. This model features a single-tier, 1-color red LED illumination housed in a black casing. The beacon's window is made from clear polycarbonate (PC), with a polycarbonate (PC) base, ensuring durability. It comes pre-wired with a 90cm / 3ft cable that terminates with bare end flying leads for easy installation. The K50BLXRXPQ operates on a supply voltage range of 12Vdc to 30Vdc, with 24Vdc as the nominal voltage. It offers versatile mounting options, including surface, base pole M30, and 1/2" NPSM thread, to accommodate different installation requirements. With a cap diameter of 50mm / 2", this beacon is designed to operate in ambient air temperatures ranging from -40°C to +50°C. It boasts a high degree of protection with ratings of IP67 and IP69K, making it suitable for challenging environments. Additionally, it features 1 x digital input (12-30Vdc; PNP) for color control, enhancing its functionality in industrial settings.
Banner Engineering K50BLXRXPQ is a high-intensity industrial LED light beacon from the EZ-LIGHT Beacons series, designed for perimeter view indication. This model features a single-tier, 1-color red LED illumination housed in a black casing. The beacon's window is made from clear polycarbonate (PC), with a polycarbonate (PC) base, ensuring durability. It comes pre-wired with a 90cm / 3ft cable that terminates with bare end flying leads for easy installation. The K50BLXRXPQ operates on a supply voltage range of 12Vdc to 30Vdc, with 24Vdc as the nominal voltage. It offers versatile mounting options, including surface, base pole M30, and 1/2" NPSM thread, to accommodate different installation requirements. With a cap diameter of 50mm / 2", this beacon is designed to operate in ambient air temperatures ranging from -40°C to +50°C. It boasts a high degree of protection with ratings of IP67 and IP69K, making it suitable for challenging environments. Additionally, it features 1 x digital input (12-30Vdc; PNP) for color control, enhancing its functionality in industrial settings.
- WirelessNo
- Pro-Editor Compatible (Discrete)No
- Modbus RTUNo
- IO LinkNo
- Feature: Quick DisconnectYes
- Feature: AudibleNo
- Indication IntensityHigh Brightness & Daylight Visible
- Multi-Color DeviceSingle Color On
- Feature: Chemical ResistantNo
- Feature: Washdown RatedYes
- Feature: Hazardous AreaNo
- Primary Window MaterialPolycarbonate Clear
- Primary Housing ColorBlack
- Min Op. Temperature (°C)-40
- Max Op. Relative Humidity Non-Condensing (%)90% @ 50°C
- Max Op. Temperature (°C)50
- Environmental RatingIP67; IP69
- NEMA Type and UL Type RatingNEMA 4X, 13
- Physical Dimensions (LxWxH or DxH mm)50.0 x 60.0
- Max Input Response Time (ms)7
- Quick Disconnect TypeM12 (Euro)
- Max Current Color (mA)140
- Supply Voltage12-30 V dc
- ConnectionIntegral QD
- Color TechnologyStandard LED
- Color Option 1Red
- Animation Option 1Solid On
- Input TypePNP
- Number of Input Pins/Conductors4
- Number of Colors / Segments1
- Color Input ControlIndividual (One wire/color, same number of colors as input wires)
- Product Size (mm)50
- Mounting ThreadM30 x 1.5
- IndicationYes
- Primary Housing MaterialPolycarbonate
- Housing StyleBase Mount - Flat Window
- Power SourceDC
- PowerDC
This part can ship within 24 hours
$128.00
Stock:
15
