Part#:DELSEF-48D

Manufacturer:Banner

Alt. Part#:85965

Product Lifecycle:Active

Get a quick Quote!

Cordset: Double Ended LS-Custom to M12; 12-pin Straight Female; 4-pin Straight Female; 2.5 m 5x22 Yellow PVC Jacket; PVC Black; Nickel-Plated Brass Coupling Nuts

About the manufacturer: Banner is one of the manufacturers that offers Cordsets that you can order at Powermatic Associates site. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.

Check out the DELSEF-48D Banner price in the box on the right side or send a quick quote.

Product Details

  • Weight
    153.2233776 g
  • Country Of Origin
    TW
  • Oil/Grease Resistant
    No
  • Secondary Number of Conductors
    5
  • Secondary Orientation
    Straight
  • Feature: Hazardous Area
    No
  • Secondary AWG
    22
  • Primary Connector Type
    LS-Custom
  • Secondary Gender
    Female
  • Primary Number of Conductors
    5
  • Secondary Coupling Method
    M12 Single Key
  • Primary Coupling Method
    EZS-LS
  • Secondary Connector Type
    EURO
  • Voltage Rating (V)
    60 V ac/75 V dc
  • Primary AWG
    22
  • Primary Gender
    Female
  • Primary Orientation
    Straight
  • Maximum Temp. (°C)
    55
  • Minimum Temp. (°C)
    -20
  • IP Rating
    IP67
  • Shield/No Shield
    No Shield
  • Cordset Length (m)
    2.5
  • Trunk Length (m)
    No Trunk
  • Coupling Material/Color
    Custom
  • Current Rating (A)
    2.0
  • Outside Cable Diameter (mm)
    6
  • Connector Body Material/Color
    PVC Black
  • Cable Jacket Color
    Yellow
  • Cable Jacket Material
    PVC
  • Number of Connectors
    2
  • Number of Contacts
    12

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

DELSEF-48D Description

Banner Engineering DELSEF-48D is a pre-assembled cable/cordset designed with a double-ended configuration, featuring a 5-pin LS female connector and a 5-pin Euro-style M12 female connector. The cable is constructed from PVC with nickel-plated brass coupling nuts, ensuring durability and a secure connection. It has a diameter of 6mm and a length of 8.2ft (2.5m), encased in yellow sheathing for easy identification. This part operates within an ambient air temperature range of -20 to +55°C and offers a degree of protection rated at IP67, making it suitable for challenging environments. The DELSEF-48D is rated for 60Vac and 75Vdc, accommodating a variety of electrical requirements.
